TemporalCommunity.DurableObjects 0.2.0

TemporalCommunity.DurableObjects

An opinionated durable-actor programming model built on the Temporal .NET SDK. It gives entity-style workflows safe defaults for atomic activation, serialized updates, contained update failures, and managed lifecycle behavior. Temporal supplies the durable execution and replay model; this library adds the actor conventions and guardrails.

Use DurableObjects for long-lived entities addressed by stable ID, such as accounts, carts, devices, sessions, and counters. Use a plain Temporal workflow for a process with a defined start and end, orchestration-heavy control flow, child workflows, signals, or direct access to the full Temporal SDK surface.

Requires Temporal Server v1.28.0 or later (Update-with-Start GA). Targets .NET 10.0, .NET 8.0, and .NET Standard 2.1. .NET 8+ receives the full feature set; the .NET Standard fallback does not support ListDurableObjectsAsync. NativeAOT client dispatch requires the generated client package. Ungenerated contracts still fall back to DispatchProxy, which is not NativeAOT-compatible.

Installation

dotnet add package TemporalCommunity.DurableObjects
dotnet add package TemporalCommunity.DurableObjects.Analyzers

Quick Start

Five steps from zero to a working DurableObject. Calling code uses a typed object contract while the library manages the Temporal start/update dispatch.

Step 1: Define the contract

Every DurableObject starts with an interface extending IDurableObject. Decorate it with [Workflow] (the Temporal SDK uses this to derive the workflow type name). Updates are fire-and-confirm ([WorkflowUpdate]); queries are synchronous reads ([WorkflowQuery]). Updates can include input validation and activity calls.

using Temporalio.Workflows;
using TemporalCommunity.DurableObjects;

[Workflow]
public interface ICounter : IDurableObject
{
    /// <summary>Adds <paramref name="amount"/> to the count. Must be positive.</summary>
    [WorkflowUpdate] Task IncrementAsync(int amount);
    [WorkflowQuery]  int  GetCount();
}

using Temporalio.Activities;

public sealed class CounterActivities
{
    /// <summary>
    /// Records an increment. In production: write to a database, emit a metric, publish an event.
    /// Activities run outside the workflow — they can do real I/O.
    /// </summary>
    [Activity]
    public Task RecordIncrementAsync(string counterId, int amount, int newTotal)
    {
        Console.WriteLine($"[audit] {counterId}: +{amount} → total {newTotal}");
        return Task.CompletedTask;
    }
}

Step 2: Implement it

Extend DurableObjectBase and implement your interface. The one mandatory boilerplate is [WorkflowRun] public Task RunAsync() => DurableObjectRunAsync(); — the SDK does not inherit [WorkflowRun] from the base class, so every concrete DurableObject must declare it. See BOILERPLATE.md for the full explanation. The [WorkflowUpdateValidator] runs before the handler body; DurableObjectBase.ExecuteActivityAsync is how workflow code triggers external I/O.

#pragma warning disable CA1822 // Workflow methods must be instance methods
using Temporalio.Workflows;
using TemporalCommunity.DurableObjects;

[Workflow]
public sealed class Counter : DurableObjectBase, ICounter
{
    private int _count;

    // Required on every concrete DurableObject — Temporal does not inherit [WorkflowRun].
    [WorkflowRun]
    public Task RunAsync() => DurableObjectRunAsync();

    // Validator: runs synchronously BEFORE IncrementAsync.
    // Throw here to reject the update before the handler body executes.
    [WorkflowUpdateValidator(nameof(IncrementAsync))]
    public void ValidateIncrementAsync(int amount)
    {
        if (amount <= 0)
            throw new ArgumentOutOfRangeException(nameof(amount), "Amount must be positive.");
    }

    [WorkflowUpdate]
    public async Task IncrementAsync(int amount)
    {
        _count += amount;

        // External I/O belongs in activities. DurableObjectBase keeps the call in the
        // workflow context; do not use ConfigureAwait(false) in workflow code.
        await ExecuteActivityAsync(
            (CounterActivities act) =>
                act.RecordIncrementAsync(WorkflowId, amount, _count),
            new ActivityOptions { StartToCloseTimeout = TimeSpan.FromSeconds(10) });
    }

    [WorkflowQuery]
    public int GetCount() => _count;
}

Step 3: Register on the worker

AddDurableObjects registers IDurableObjectFactory in DI (client-side). AddDurableObjectWorkflows scans the assembly and registers the workflow types on the worker (worker-side). Both go in the same service configuration; they serve different roles.

// Using Temporalio.Extensions.Hosting
services.AddTemporalClient(opts => opts.TargetHost = "localhost:7233");

// Client-side: registers IDurableObjectFactory with DefaultTaskQueue = "my-task-queue"
services.AddDurableObjects("my-task-queue");

// Worker-side: scans the assembly, registers DurableObject workflow types and activities
services.AddHostedTemporalWorker("my-task-queue")
        .AddDurableObjectWorkflows(typeof(Counter).Assembly)
        .AddSingletonActivities<CounterActivities>();

Without AddSingletonActivities, no worker can pick up the activity; the update eventually fails according to its activity timeout and retry policy.

Step 4: Call it

Inject IDurableObjectFactory and use the generated client extension. The object ID remains a Temporal workflow ID, while the concrete client handles update-with-start and asynchronous query dispatch without reflection.

using Temporalio.Exceptions;

public class MyService(IDurableObjectFactory factory)
{
    public async Task RunAsync()
    {
        // Generated from ICounter by TemporalCommunity.DurableObjects.Analyzers.
        var counter = factory.GetCounterClient("my-counter");

        await counter.IncrementAsync(5);  // validator passes; activity records the increment
        int count = await counter.GetCountAsync(); // 5; no blocked caller thread

        try
        {
            await counter.IncrementAsync(-1);
        }
        catch (WorkflowUpdateFailedException)
        {
            // Expected: the validator rejects this before the handler body runs.
        }

        count = await counter.GetCountAsync(); // still 5; the object remains alive
    }
}

WorkflowUpdateFailedException is thrown on the caller side; the object remains alive. Inspect ApplicationFailureException.ErrorType in the chain. See FAILURE_HANDLING.md for the full taxonomy.

Step 5: Verify

dotnet run

The counter object starts on first update. Its state is recovered from Temporal history after worker restarts and compatible re-deployments. For state that must cross Continue-as-New, derive from DurableObjectBase<TState> as shown in the Getting Started sample; the non-generic base continues to support explicit carry-forward through OnBeforeContinueAsNewAsync().

What happens when an update throws?

If an update handler throws an unexpected exception, DurableObjectWorkerInterceptor catches it and converts it to an ApplicationFailureException so the object does not wedge permanently. On the calling side, the exception chain is: WorkflowUpdateFailedException wraps an ApplicationFailureException, which carries the original error in InnerException. Inspect ApplicationFailureException.ErrorType for domain-specific error codes (e.g. "Unauthorized", "UnhandledUpdateException"). See FAILURE_HANDLING.md for the full exception taxonomy, lifecycle hook failure behavior, and authorization patterns.

Key Concepts

Tier model

Objects have three lifecycle tiers. V1 ships Tier 1 and Tier 3. See TIER_MODEL.md.

Deactivation semantics

When deactivation is triggered (via DeactivateAsync() from outside, or Deactivate() from inside a handler), the object drains before closing:

• In-flight updates complete. Any update handler already executing when deactivation is signaled runs to completion before the object closes. New updates arriving after the signal is received are rejected with errorType: "ObjectDeactivating".
• Reactivation is always possible. After an object deactivates, the next GetOrCreate or update-with-start call on the same ID spins up a fresh execution under WorkflowIdReusePolicy.AllowDuplicate. The object effectively restarts clean.
• Drain timeout is not configurable in v1. The drain waits on Workflow.WaitConditionAsync(() => Workflow.AllHandlersFinished) with no deadline. Design update handlers to complete promptly; avoid long-running blocking operations inside handlers.

ContinueAsNew and state preservation

ContinueAsNew is triggered automatically when Workflow.CurrentHistoryLength exceeds the MaxHistoryLength threshold (default 10,000 events) or when the Temporal server sets Workflow.ContinueAsNewSuggested. DurableObjectBase<TState> carries its protected State in a typed DurableObjectSnapshot<TState> automatically. The concrete workflow declares matching optional snapshot parameters on its [WorkflowInit] constructor and [WorkflowRun] method. Applications remain responsible for serialization-compatible evolution of TState.

The non-generic DurableObjectBase does not infer which fields are state. Objects using it must override OnBeforeContinueAsNewAsync() and keep its argument shape compatible with the workflow initializer. Otherwise mutable fields reset after Continue-as-New.

Object identity and namespace scope

Object IDs are globally unique within a Temporal namespace — not per-task-queue. Two workers registered on different task queues in the same namespace cannot both own an object with the same ID unless they are both registered for the same workflow type. If a second worker issues GetOrCreate for an ID that is already owned by a different workflow type, Temporal will route the start to the existing execution's task queue (the one it was originally started on), not the caller's queue. Use distinct ID namespacing conventions (e.g., prefixes) to avoid accidental cross-type collisions.

The library never rewrites or prefixes IDs. On .NET 8+, use ListDurableObjectExecutionsAsync<T>() for run ID, status, task queue, timestamps, history length, and schedule origin. It returns running canonical objects by default; pass new DurableObjectListOptions(includeScheduled: true) to include schedule-created executions.

Reminders vs Schedules

Two mechanisms trigger recurring behavior in DurableObjects — they serve different roles:

The key difference: reminders keep one long-lived object alive and deliver updates to it; schedules spin up a new execution per tick and expect that execution to call Deactivate() on completion.

DurableObject vs plain Temporal workflow

DurableObjects do not add persistence outside Temporal or provide cross-object transactions. “Resident” means the workflow execution remains open; it does not mean a CLR object is always loaded in worker memory. Typed interface queries are synchronous and park the calling thread; use QueryDurableObjectAsync on asynchronous or high-throughput call paths.

Signals are banned — use updates

All methods on a DurableObject interface must be [WorkflowUpdate] or [WorkflowQuery]. [WorkflowSignal] is banned in v1, including on framework-provided methods. Signals bypass the authorization hook, give callers no confirmation, and offer no rollback on partial state mutation. See ADR 005.

Generated asynchronous clients and NativeAOT

Installing TemporalCommunity.DurableObjects.Analyzers generates a concrete client for every public, non-generic DurableObject contract. For ICounter, call factory.GetCounterClient("counter-id"); updates keep their contract names and queries gain asynchronous methods such as GetCountAsync(). Every generated method also has an overload that accepts DurableObjectCallOptions.

The factory registry automatically prefers the generated concrete implementation even when code continues to call factory.Get<ICounter>(). Contracts the generator cannot handle produce DO0005; contracts compiled without the generator retain the documented DispatchProxy fallback. Only the generated client path is NativeAOT-compatible—this does not claim that every worker-discovery feature in the Temporal SDK is reflection-free. See ADR 009.

API Reference

Per-call cancellation, timeouts, and metadata

Use DurableObjectCallOptions when an update or query needs a deadline, retry override, or gRPC metadata. Options are captured by the local client and never become workflow arguments:

var counter = factory.GetCounterClient(
    "home",
    new DurableObjectCallOptions(
        rpcTimeout: TimeSpan.FromSeconds(5),
        metadata: new Dictionary<string, string>
        {
            ["authorization"] = $"Bearer {accessToken}",
        },
        cancellationToken: cancellationToken));

await counter.IncrementAsync();

Cancelling the token stops waiting for the client RPC. It does not cancel an update that Temporal has already accepted. Create another proxy when a later call needs different options.

IDurableObjectFactory methods

DurableObjectBase lifecycle hooks

Override any of these in your class. All have no-op defaults.

DurableObjectBase<TState> adds a protected State property and automatically carries it through Continue-as-New in DurableObjectSnapshot<TState>. Use PrepareStateForContinueAsNewAsync only when state needs deterministic normalization before the next execution.

DurableObjectWorkerInterceptor options

Pass via AddDurableObjectWorkflows(assembly, options):

The interceptor is installed automatically by AddDurableObjectWorkflows. It also wraps arbitrary update handler exceptions into clean ApplicationFailureException rejections so the object does not wedge permanently. See FAILURE_HANDLING.md.

Failure Handling

Exception mapping, update handler failure taxonomy, lifecycle hook failure behavior, authorization patterns, and reminder idempotency — see FAILURE_HANDLING.md.

Versioning

Long-lived DurableObjects accumulate workflow history. Changes to handler names, signatures, and ContinueAsNew constructor schemas require care. See ADR 004 for the full versioning strategy: what is safe, what requires Workflow.Patched, and how to deploy new versions safely.

Object-to-Object Communication

Direct DurableObject-to-DurableObject messaging is deferred from v1. The v1 workaround is an Activity that calls the target object via ITemporalClient:

[Activity]
public class CallCounterActivity(IDurableObjectFactory factory)
{
    public async Task<int> GetRemoteCountAsync(string targetId)
    {
        var counter = factory.Get<ICounter>(targetId);
        return counter.GetCount();
    }
}

Execute it from inside an update handler:

[WorkflowUpdate]
public async Task SyncFromRemoteAsync(string remoteId)
{
    _count = await ExecuteActivityAsync(
        (CallCounterActivity a) => a.GetRemoteCountAsync(remoteId),
        new ActivityOptions { StartToCloseTimeout = TimeSpan.FromSeconds(30) });
}

Three candidate designs (Activity-mediated, child workflows, Nexus) are under evaluation for v1.1. See ADR 003.

Samples

Six runnable samples covering the core features are in samples/. See samples/README.md for the full index. Each sample requires a live Temporal server (temporal server start-dev).

just run-sample                    # 01-getting-started (default)
just run-sample 03-scheduling      # specific sample by directory name
just run-sample-all                # list all available samples

Building from Source

Prerequisites: .NET 10 SDK, just.

dotnet tool restore     # install minver-cli and reportgenerator
just build              # restore + compile (Release)
just test               # unit + integration tests
just pack               # produces artifacts/packages/*.nupkg
just doctor             # verify all prerequisites

Run just with no arguments to list all available recipes.

Common recipes

Documentation

• Getting Started guide — reading order, document map, and quick links for new developers.
• Boilerplate guide — required patterns every DurableObject must follow.
• Failure handling — exception taxonomy, authorization, and reminder idempotency.
• Tier model — lifecycle tiers and ContinueAsNew behavior.
• Troubleshooting — common mistakes and how to fix them.
• Temporal analyzers — opt-in compile-time determinism and DurableObjects contract checks.
• ADRs — maintainer-facing architectural decisions and design rationale.

Contributing

1. Fork and clone.
2. dotnet tool restore once after cloning.
3. Run just ci before opening a PR — this is what CI runs.
4. For integration tests: just test-integration (no external Temporal server needed; it uses WorkflowEnvironment.StartLocalAsync()).
5. Add an ADR in adr/ for any architectural decision, API surface change, or significant constraint. Follow the format in the existing ADRs.

License

MIT — see LICENSE.
