SwitchboardApplicationProxy 3.0.2

<img src="https://github.com/jchristn/switchboard/blob/main/assets/icon.png?raw=true" width="140" height="128" alt="Switchboard">

Switchboard

Switchboard is a lightweight application proxy combining reverse proxy and API gateway functionality. Switchboard can be integrated directly into your app or run as a standalone server.

Help, Feedback, Contribute

If you have any issues or feedback, please file an issue here in Github. We'd love to have you help by contributing code for new features, optimization to the existing codebase, ideas for future releases, or fixes!

New in v3.0.x

• Added origin server healthchecks and ratelimiting

Default Configuration

By default, Switchboard server will listen on http://localhost:8000/ and is not configured with API endpoints or origin servers (see below for an example). If you point your browser to http://localhost:8000/ you will see a default page indicating that the node is operational. HEAD requests to this URL will also return a 200/OK.

If not explicitly set, origin servers will have their health checked along the following parameters:

• Using GET /
• Checked every five seconds (see HealthCheckIntervalMs)
• Two consecutive failures (see UnhealthyThreshold) marks an origin server as unhealthy
• Two consecutive successes (see HealthyThreshold) marks an origin server as healthy

If not explicitly set, origin server rate limiting will be enforced along the following parameters:

• Up to 10 parallel requests can be handled at a time (see MaxParallelRequests) per origin server
• Up to 30 requests can be in process and pending at a time (see RateLimitRequestsThreshold) per origin server

Example (Integrated)

Refer to the Test project for a working example with one API endpoint and four origin servers.

using Switchboard.Core;

// initialize settings
SwitchboardSettings settings = new SwitchboardSettings();

// add API endpoints
settings.Endpoints.Add(new ApiEndpoint
{
    Identifier = "my-api-endpoint",
    Name = "My API endpoint",
    LoadBalancing = LoadBalancingMode.RoundRobin,
    Unauthenticated = new ApiEndpointGroup // URLs that do not require authentication via the authentication callback
    {
        ParameterizedUrls = new Dictionary<string, List<string>>
        {
            { "GET", new List<string> { "/unauthenticated" } },
        }
    },
    Authenticated = new ApiEndpointGroup // URLs that require authentication via the authentication callback
    {
        ParameterizedUrls = new Dictionary<string, List<string>>
        {
            { "GET", new List<string> { "/authenticated" } },
            { "GET", new List<string> { "/users/{UserGuid}" } }
        }
    },
    RewriteUrls = new Dictionary<string, Dictionary<string, string>>
    {
        {
            "GET", new Dictionary<string, string>
            {
                "/users/{UserGuid}", "/{UserGuid}" // rewrite /users/foo to just /foo
            }
        }
    },
    OriginServers = new List<string>
    {
        "my-origin-server"
    }
});

// add origin servers
settings.Origins.Add(new OriginServer
{
    Identifier = "my-origin-server",
    Name = "My origin server",
    Hostname = "localhost",
    Port = 8001,
    Ssl = false
});

// define the authentication and authorization callback
private static async Task<AuthContext> AuthenticateAndAuthorizeRequest(HttpContextBase ctx)
{
    return new AuthContext
    {
        Authentication = new AuthenticationContext
        {
            Result = AuthenticationResultEnum.Success,
            Metadata = new Dictionary<string, string>() // use this object as you wish
            {
                { "Authenticated", "true" }
            }
        },
        Authorization = new AuthorizationContext
        {
            Result = AuthorizationResultEnum.Success,
            Metadata = new Dictionary<string, string>() // use this object as you wish
            {
                { "Authorized", "true" }
            }
        },
        Metadata = new Dictionary<string, string>() // use this object as you wish
        {
            { "Allow", "true" }
        }
    };
}

// start Switchboard
using (SwitchboardDaemon sb = new SwitchboardDaemon(settings))
{
    sb.Callbacks.AuthenticateAndAuthorize = AuthenticateAndAuthorizeRequest;
    ...
}

Example (Standalone)

$ cd /path/to/src-directory
$ dotnet build
$ cd Switchboard.Server/bin/Debug/net8.0
$ dotnet Switchboard.Server.dll


            _ _      _    _                      _
  ____ __ _(_) |_ __| |_ | |__  ___  __ _ _ _ __| |
 (_-< V  V / |  _/ _| ' \| '_ \/ _ \/ _` | '_/ _` |
 /__/\_/\_/|_|\__\__|_||_|_.__/\___/\__,_|_| \__,_|


Switchboard Server v3.0.0

Loading from settings file ./sb.json
2024-12-05 03:30:01 INSPIRON-14 Info [SwitchboardDaemon] webserver started on http://localhost:8000
2024-12-05 03:30:01 INSPIRON-14 Info [SwitchboardDaemon] Switchboard Server started using process ID 49308

Docker

A Docker image is available in Docker Hub under jchristn/switchboard. Use the Docker Compose start (compose-up.sh and compose-up.bat) and stop (compose-down.sh and compose-down.bat) scripts in the Docker directory if you wish to run within Docker Compose. Ensure that you have a valid configuration file (e.g. sb.json) exposed into your container.

Version History

Refer to CHANGELOG.md for version history.
