SharpBoxesCore.Wpf 1.1.0

🎯 SharpBoxesCore.Wpf.PropertyGrid

一个功能强大、高度可扩展的 WPF 属性编辑器（PropertyGrid），专为现代 MVVM 应用设计。支持自动 UI 生成、属性分组、描述显示、范围验证、滑块调节、自定义按钮、命令绑定等高级功能，开箱即用，适用于配置面板、调试工具、设计器等场景。

✨ 核心特性

🚀 快速开始

1. 安装引用

将 PropertyGrid.xaml 和 PropertyGrid.xaml.cs 添加到你的 WPF 项目中。

2. 在 XAML 中使用

<Window x:Class="YourApp.MainWindow"
        xmlns:local="clr-namespace:SharpBoxesCore.Wpf.PropertyGrid"
        ...>
    <Grid>
        <local:PropertyGrid x:Name="propertyGrid" />
    </Grid>
</Window>

3. 绑定数据对象

public partial class MainWindow : Window
{
    public MainWindow()
    {
        InitializeComponent();
        propertyGrid.SelectedObject = new SampleObject();
    }
}

📦 示例：完整数据模型

public class SampleObject : INotifyPropertyChanged
{
    private string _name = "示例对象";
    private int _age = 25;
    private double _height = 175.5;
    private SampleEnum _category = SampleEnum.选项一;
    private Priority _priority = Priority.Normal;
    private bool _isActive = true;
    private string _description = "这是一个示例对象的描述";

    public ICommand OpenFileCommand =>
        new RelayCommand<string>(action =>
        {
            if (action == "浏览...")
            {
                OpenFileDialog dialog = new OpenFileDialog();
                dialog.Filter = "所有文件|*.*";
                if (dialog.ShowDialog() == true)
                {
                    FilePath = dialog.FileName;
                }
            }
            else if (action == "打开文件夹")
            {
                if (System.IO.File.Exists(FilePath))
                {
                    Process.Start("explorer.exe", Path.GetDirectoryName(FilePath));
                }
            }
            OnPropertyChanged(nameof(FilePath));
        });

    public ICommand AddNameCommand => new RelayCommand(() =>
    {
        AvaliableNames.Add($"Item_{AvaliableNames.Count}");
    });

    [Category("调试")]
    [DisplayName("重置计数")]
    [Description("点击按钮可重置或刷新计数")]
    [AddButton("递增")]
    [AddButton("重置")]
    [AddButton("AddNameCommand", "日志")] // 多个 [AddButton] 也支持
    public int Count { get; set; } = 0;

    [Category("文件")]
    [DisplayName("路径")]
    [AddButton("OpenFileCommand", "浏览...")]
    [AddButton("OpenFileCommand", "打开文件夹")]
    public string FilePath { get; set; } = "";

    [Category("基本信息")]
    [Description("对象的名称，用于标识该对象")]
    [PropertyOrder(1)]
    [DisplayName("名称")]
    [EnumerableProperty("AvaliableNames", true)] // 允许自定义
    public string Name
    {
        get { return _name; }
        set
        {
            if (_name != value)
            {
                _name = value;
                OnPropertyChanged(nameof(Name));
            }
        }
    }

    [Category("基本信息")]
    [Description("对象的年龄，必须为正整数")]
    [PropertyOrder(2)]
    [DisplayName("年龄")]
    public int Age
    {
        get { return _age; }
        set
        {
            if (_age != value)
            {
                _age = value;
                OnPropertyChanged(nameof(Age));
            }
        }
    }

    [Category("基本信息")]
    [Description("对象的身高，单位为厘米，支持小数")]
    [PropertyOrder(3)]
    [DisplayName("身高")]
    [Range(100, 400)]
    [ShowSlider(10, true)] // 每10一个刻度，吸附
    public double Height
    {
        get { return _height; }
        set
        {
            if (_height != value)
            {
                _height = value;
                OnPropertyChanged(nameof(Height));
            }
        }
    }

    [Category("分类设置")]
    [Description("对象所属的类别，从预定义的选项中选择")]
    [PropertyOrder(1)]
    [DisplayName("类别")]
    public SampleEnum Category
    {
        get { return _category; }
        set
        {
            if (_category != value)
            {
                _category = value;
                OnPropertyChanged(nameof(Category));
            }
        }
    }

    [Category("分类设置")]
    [Description("对象的优先级，影响处理顺序")]
    [PropertyOrder(2)]
    [DisplayName("优先级")]
    public Priority Priority
    {
        get { return _priority; }
        set
        {
            if (_priority != value)
            {
                _priority = value;
                OnPropertyChanged(nameof(Priority));
            }
        }
    }

    [Category("状态控制")]
    [Description("标识对象是否处于活动状态")]
    [PropertyOrder(1)]
    [DisplayName("活动状态")]
    public bool IsActive
    {
        get { return _isActive; }
        set
        {
            if (_isActive != value)
            {
                _isActive = value;
                OnPropertyChanged(nameof(IsActive));
            }
        }
    }

    [Category("其他信息")]
    [Description("对象的详细描述信息，可以包含多行文本")]
    [PropertyOrder(1)]
    [DisplayName("描述")]
    [EnumerableProperty("AvaliableNames", false)] // 允许自定义
    public string Description
    {
        get { return _description; }
        set
        {
            if (_description != value)
            {
                _description = value;
                OnPropertyChanged(nameof(Description));
            }
        }
    }

    public event PropertyChangedEventHandler PropertyChanged;

    protected virtual void OnPropertyChanged([CallerMemberName]string propertyName="")
    {
        PropertyChanged?.Invoke(this, new PropertyChangedEventArgs(propertyName));
    }

    // 数据源（下拉选项）
    private ObservableCollection<string> _avaliableNames = new ObservableCollection<string> { "A", "B" };
    public ObservableCollection<string> AvaliableNames
    {
        get => _avaliableNames;
        set
        {
            _avaliableNames = value;
            OnPropertyChanged();
        }
    }

    [Category("文件")]
    [DisplayName("配置文件")]
    [SelectFilePath(Title = "选择配置文件", Filter = "JSON Files|*.json|All Files|*.*")]
    public string ConfigFile { get; set; } = "";

    [Category("路径")]
    [DisplayName("工作目录")]
    [SelectFolder]
    public string WorkDir { get; set; } = "";

    [Category("选项")]
    [DisplayName("主题")]
    [EnumerableProperty("AvailableThemes", true)]
    public string Theme { get; set; } = "Dark";

    public List<string> AvailableThemes { get; } = new() { "Light", "Dark", "Blue" };
}

🎨 UI 效果预览

（建议补充一张截图）

• 分组折叠/展开
• 滑块与文本框联动
• 按钮自动布局
• 错误输入红色提示
• 描述信息实时显示

🔧 高级功能详解

1. 枚举显示 [Description]

public enum Quality
{
    [Description("高清")]
    High,

    [Description("标清")]
    Medium,

    [Description("低清")]
    Low
}

✅ 显示为“高清”而非 High

2. 滑块调节 [ShowSlider]

[Range(0, 100)]
[ShowSlider(5, true)] // 每5一格，吸附
public int Brightness { get; set; }

✅ 自动生成 Slider + TextBox 联动控件

3. 自定义按钮与命令绑定

[AddButton("SaveCommand", "保存", "另存为")]
[AddButton("DeleteCommand", "删除")]
public string FileName { get; set; }

public ICommand SaveCommand => new RelayCommand<string>(...);
// DeleteCommand 未定义 → fallback 到事件

✅ 存在命令：绑定执行
❌ 不存在：触发 ButtonClicked 事件

propertyGrid.ButtonClicked += (sender, e) =>
{
    MessageBox.Show($"执行: {e.PropertyName} - {e.ButtonText}");
};

4. 数值范围验证

[Range(1, 1000)]
public int Count { get; set; }

✅ 输入非法时：

• 边框变红
• 显示错误提示
• 不更新数据源

🧩 事件与回调

ButtonClicked 事件（fallback 机制）

propertyGrid.ButtonClicked += (sender, e) =>
{
    string property = e.PropertyName;
    string button = e.ButtonText;

    // 统一处理未绑定命令的按钮
    switch (property)
    {
        case "RetryCount":
            if (button == "重置") ((SampleObject)propertyGrid.SelectedObject).RetryCount = 0;
            break;
    }
};

🛠️ 自定义 Attribute 说明

📚 已知限制

• ❌ 暂不支持 DateTime 专用控件（可用 TextBox）

✅ 后续版本将支持 DatePicker、ColorPicker、FilePathEditor[已支持] 、FolderEditor[已支持]等。

🤝 贡献与反馈

欢迎提交 Issue 或 Pull Request！
项目地址：https://github.com/yourname/sharpboxes-core

📄 许可证

MIT License

🔧 由 SharpBoxesCore 团队打造 —— 让 WPF 开发更简单！
