Play Nicely - Projects

Play Nicely Projects supports the virtual definition of MSBuild projects, and interfaces for reading and writing packaged projects from/to media. These projects can be used to release test NuGet tool packages that you may be developing. This package provides foundation artefacts for tool project testing, however, the actual test execution code and supporting BDD extensions are developed separately, in these projects.

• PlayNicely.Executor
• PlayNicely.Executor.DotNet
• PlayNicely.SpecFlow.Executor
• PlayNicely.SpecFlow.DotNet

These packages are used by these tools, among others:

• PlayNicely.NpmNpx
• PlayNicely.Sass

Getting Started

This base package supports the definition of a TestCaseProject via a virtual FileSystem interface. This interface allows for the definition of directories and files, and also the contents of those files.

The other artefacts support reading or writing of a TestCaseProject from/to media. At this time, the project supports reading from .NET assembly resources and writing to the physical file system. Implement concrete versions of IProjectPackageReader or IProjectPackageWriter if you have a specific media that is not currently supported.

Defining Projects

The TestCaseProject class represents a virtual project, you can define a FileSystem by adding directories and files using its fluent interface. You can also specify which file is the ProjectFile from the same file system. Once defined the TestCaseProject doesn't do much on its own, but when combined with PlayNicely.Executor, or other dependent packages, it can have commands executed against it and any output collected for assertions.

var testCaseProject = new TestCaseProject("my-project");

// Define the project file system
var projectFile = testCaseProject.Root.AddDirectory("project1")
                                      .AddFile("proj.csproj");

testCaseProject.ProjectFile = projectFile;

using(var writer = new StreamWriter(projectFile.OpenWriteStream()))
{
    writer.WriteLine("<Project Sdk=\"Microsoft.NET.Sdk\">");
    writer.WriteLine("  <PropertyGroup>");
    writer.WriteLine("    <TargetFramework>netstandard2.0</TargetFramework>");
    writer.WriteLine("  </PropertyGroup>");
    writer.WriteLine("</Project>");
}

Using Resource (resx) files

Building test case projects in code is fine, but it would be helpful if we could define them declaritively as well. The base package supports this by defining projects in resx files and loading them into a TestCaseProject at runtime.

You would typically use this concept within the IDE, see next section, but you don't have to, you can declare the project using raw XML within a resx file.

To load a TestCaseProject from a resource in an assembly, you use the ResourceSetPackageReader class and pass it to the TestCaseProject.LoadFromAsync method. The constructor requires a ResourceSet, or you can use one of the static Create methods. If you have a .resx file with a generated class, the easiest way to load the resource into a TestCaseProject is like this:

// Resx file is called Project1.resx with generation _on_
using var reader = ResourceSetPackageReader.Create<Project1>();
var testCaseProject = new TestCaseProject("Project1");

await testCaseProject.LoadFromAsync(reader);

Example

This example defines a TestCaseProject within a resx file. Using item keys and values (for the file content).

If you want a TestCaseProject with the following structure:

solution-dir
|-- Project1
|   |-- Project1.csproj
|   |-- Program.cs
|
|-- Project2
|   |-- Project2.csproj
|   |-- Program.cs
|   |-- Consts.cs
|
|-- my-solution.sln

The resx file should have the following resources defined (note the item keys represent paths), and also the special ProjectFile key, the value of which is the path to the project file. If this key is present it sets the TestCaseProject.ProjectFile property to the file at that path.

<?xml version="1.0" encoding="utf-8"?>
<root>

  <data name="ProjectFile" xml:space="preserve">
    <value>my-solution.sln</value>
  </data>
  <data name="my-solution.sln" xml:space="preserve">
    <value>...Excluded for bereveity...</value>
  </data>

  <data name="Project1/Project1.csproj" xml:space="preserve">
    <value>
&lt;Project Sdk="Microsoft.NET.Sdk"&gt;
  &lt;PropertyGroup&gt;
    &lt;TargetFramework&gt;net6.0&lt;/TargetFramework&gt;
  &lt;/PropertyGroup&gt;
&lt;/Project&gt;
    </value>
  </data>
  <data name="Project1/Program.cs" xml:space="preserve">
    <value>
using System;

namespace Project1
{
    public static class Program
    {
        public static int Main(params string[] args)
        {
            Console.WriteLine("Project1");

            return 0;
        }
    }
}
    </value>
  </data>

  <data name="Project2/Project2.csproj" xml:space="preserve">
    <value>
&lt;Project Sdk="Microsoft.NET.Sdk"&gt;
  &lt;PropertyGroup&gt;
    &lt;TargetFramework&gt;net6.0&lt;/TargetFramework&gt;
  &lt;/PropertyGroup&gt;
&lt;/Project&gt;
    </value>
  </data>
  <data name="Project2/Program.cs" xml:space="preserve">
    <value>
using System;

namespace Project1
{
    public static class Program
    {
        public static int Main(params string[] args)
        {
            Console.WriteLine("Project2: {0}", Consts.Version);

            return 0;
        }
    }
}
    </value>
  </data>
  <data name="Project2/Consts.cs" xml:space="preserve">
    <value>
using System;

namespace Project1
{
    public static class Consts
    {
        public const string Version = "1.2.3";
    }
}
    </value>
  </data>
</root>

Using the IDE

Ok, so defining test case projects in code isn't ideal, neither is creating raw resx files, really we want to use a familiar tool, i.e. the IDE. Rather than specify file content using raw strings, as in the example above, we can define projects in Visual Studio as normal, Add Project..., New Item..., etc., and then reference them in the resx file for packaging.

⚠ Watch out for Visual Studio behavior
When you reference files, in a .resx file, from outside the project directory, Visual Studio has a tendancy to copy them into the project structure. You may need to edit the resx files as XML and update these paths, to point to the correct file, as well as delete the copied files.

Our recomended setup for tool projects that require test cases, is to create a solution structure like this.

solution-dir
|-- Project.UnderTest.Specs    # BDD Specifications for your project
|   |-- TestCases.Projects     # Define your test case 'packages' in resx files
|       |-- Project1.resx
|
|-- TestCase.Projects          # Define your test case projects in here using familiar tools.
|   |-- Project1
|       |-- Project1.csproj
|       |-- Program.cs
|
|-- Project.UnderTest          # The package project that needs to be tested before release
|   |-- Project.UnderTest.csproj
|   |-- SomeCode.cs
|
|-- solution.sln

Key points to consider:

• The Project.UnderTest is the actual payload project of this repository.

• Project.UnderTest.Specs is a BDD project that tests the capabilities of Project.UnderTest.

  • The Project1.resx resource references the files from TestCase.Projects/Project1 directory with ResXFileRef items.

• The TestCase.Projects directory is a space to define the test case projects, within the IDE. You can add new projects, new classes, interfaces, whatever you need in a familiar environment.

  ⚠ Unhappy path projects
  Beware, if this is an unhappy path test, that you need to exclude it from the solution build, Configuration Manager....

The source below is an example of how the resx file's content should be set.

<?xml version="1.0" encoding="utf-8"?>
<root>

  <data name="Project1/Project1.csproj" type="System.Resources.ResXFileRef, System.Windows.Forms">
    <value>../../TestCase.Projects/Project1/Project1.csproj;System.String, mscorlib, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089;utf-8</value>
  </data>
  <data name="Project1/Program.cs" type="System.Resources.ResXFileRef, System.Windows.Forms">
    <value>../../TestCase.Projects/Project1/Program.cs;System.String, mscorlib, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089;utf-8</value>
  </data>
</root>

Example

The best examples, are real uses, you can find them in these dependent projects.

• PlayNicely.NpmNpx
• PlayNicely.Sass
