FlexiPane 1.0.0-dev.13

FlexiPane.WPF

A modern and flexible WPF screen splitting library for dynamic pane management. Create resizable, dockable panels with intuitive split controls and visual feedback.

<div align="center"> <img src="images/Screenshot1.png" alt="FlexiPane Split Layout" width="49%" /> <img src="images/Screenshot2.png" alt="FlexiPane Split Mode" width="49%" />

Left: Multiple panels with complex split layout | Right: Interactive split mode with visual guides </div>

✨ Features

• 🎯 Interactive Split Overlays - Mouse-driven splitting with visual direction guides and hover feedback
• 🎨 Toggle Split Mode - Simple boolean property to enable/disable splitting functionality
• 🔄 Smart Panel Management - Advanced visual tree management with proper disposal and cleanup
• 🎮 Programmatic Control - Built-in methods for splitting selected panels programmatically
• 🎯 Focus & Selection - Automatic focus tracking with visual selection indicators
• 📐 Flexible Layouts - Support for complex nested split arrangements with layout serialization
• 🔌 Event-Driven Architecture - Unified ContentRequested event system for dynamic content
• 🎨 Automatic Content Wrapping - Any UIElement gets automatically wrapped for splitting capability
• ⚡ High Performance - Pure WPF implementation with optimized rendering and template caching
• 🛡️ Safe Mode Toggling - Split mode can be toggled on/off without losing existing layouts
• 🎛️ Minimal Configuration - Works with just <flexiPane:FlexiPanel /> in XAML
• ⌨️ Full Keyboard Support - ESC key handling, focus navigation, and accessibility support
• 💾 Layout Persistence - Save and load complex panel layouts to/from files
• 🔧 Robust Error Handling - Comprehensive validation and graceful degradation

📦 Installation

Package Manager Console

Install-Package FlexiPane.WPF

.NET CLI

dotnet add package FlexiPane.WPF

PackageReference

<PackageReference Include="FlexiPane.WPF" Version="1.0.0" />

🚀 Quick Start

Add the namespace to your XAML:

xmlns:flexiPane="clr-namespace:FlexiPane.Controls;assembly=FlexiPane"

Simple Usage

Use the simplest possible configuration for basic split functionality:

<Grid>
  <Grid.RowDefinitions>
    <RowDefinition Height="Auto" />
    <RowDefinition Height="*" />
  </Grid.RowDefinitions>


  <StackPanel Grid.Row="0" Orientation="Horizontal" Margin="10">
    <ToggleButton x:Name="ModeToggleButton" Content="Toggle Split Mode" Padding="10,5" />
  </StackPanel>


  <flexiPane:FlexiPanel
    x:Name="FlexiPanel"
    Grid.Row="1"
    IsSplitModeActive="{Binding ElementName=ModeToggleButton, Path=IsChecked}"
    ContentRequested="OnContentRequested"
    />
</Grid>

Unified Event-Driven Content Generation

The panel uses a unified event-driven architecture for all content requests:

// Handle all content requests - both initial and split operations
private void OnContentRequested(object sender, ContentRequestedEventArgs e)
{
    // Handle initial panel content
    if (e.RequestType == ContentRequestType.InitialPane)
    {
        e.RequestedContent = new Border
        {
            Background = Brushes.LightBlue,
            Child = new TextBlock
            {
                Text = $"Initial Panel {DateTime.Now:HH:mm:ss}",
                HorizontalAlignment = HorizontalAlignment.Center,
                VerticalAlignment = VerticalAlignment.Center
            }
        };
        e.Handled = true;
    }
    // Handle split panel content
    else if (e.RequestType == ContentRequestType.SplitPane)
    {
        e.RequestedContent = new Border
        {
            Background = Brushes.LightGreen,
            Child = new TextBlock
            {
                Text = $"Split Panel {DateTime.Now:HH:mm:ss}\nDirection: {(e.IsVerticalSplit == true ? "Vertical" : "Horizontal")}",
                HorizontalAlignment = HorizontalAlignment.Center,
                VerticalAlignment = VerticalAlignment.Center
            }
        };
        e.Handled = true;
    }
}

Programmatic Splitting

Split the selected panel programmatically:

// Split vertically at 50%
flexiPanel.SplitSelectedVertically(0.5);

// Split horizontally with custom content
var customContent = new TextBlock { Text = "New Panel" };
flexiPanel.SplitSelectedHorizontally(0.3, customContent);

Handling Panel Lifecycle Events

Customize behavior through comprehensive events:

// Validate panel closing
flexiPanel.PaneClosing += (s, e) => {
    if (HasUnsavedChanges(e.Pane)) {
        e.Cancel = MessageBox.Show("Discard changes?", "Confirm",
            MessageBoxButton.YesNo) == MessageBoxResult.No;
    }
};

// Handle last panel scenario
flexiPanel.LastPaneClosing += (s, e) => {
    e.Cancel = MessageBox.Show("Close last panel?", "Confirm",
        MessageBoxButton.YesNo) == MessageBoxResult.No;
};

// Track split mode changes
flexiPanel.SplitModeChanged += (s, e) => {
    statusLabel.Text = $"Split Mode: {(e.IsActive ? "ON" : "OFF")}";
};

Architecture

Core Components

• FlexiPanel - Root container managing the entire pane structure
• FlexiPaneItem - Individual panels containing user content with interactive split overlays
• FlexiPaneContainer - Split containers holding two children with resizable GridSplitter
• FlexiPaneManager - Manager handling split/close operations with proper visual tree management

Tree Structure

The library uses a binary tree structure for managing panels:

FlexiPanel
└── RootContent
    ├── FlexiPaneItem (leaf node)
    └── FlexiPaneContainer (branch node)
        ├── FirstChild
        └── SecondChild

Advanced Features

Interactive Split Mode UI

Enable interactive split mode with visual overlays and mouse interaction:

<ToggleButton x:Name="SplitToggle" Content="Toggle Split Mode" />
<flexiPane:FlexiPanel IsSplitModeActive="{Binding ElementName=SplitToggle, Path=IsChecked}" />

Or programmatically:

flexiPanel.IsSplitModeActive = true;
// Interactive split overlays and close buttons are automatically shown

When split mode is active:

• Interactive Split Overlays: Hover over panels to see split direction guides
• Mouse-Based Splitting: Click on overlay regions to split vertically/horizontally
• Visual Direction Guides: Clear indicators showing split direction and guide lines
• Keyboard Navigation: ESC to exit split mode, focus handling for accessibility
• Smart Close Operations: Close buttons with proper visual tree cleanup
• Toggle off safely: Disabling split mode preserves all existing panels

Automatic Content Wrapping

The library automatically handles different content types:

private void OnContentRequested(object sender, ContentRequestedEventArgs e)
{
    // Return any UIElement - FlexiPanel automatically wraps it for splitting
    e.RequestedContent = new UserControl(); // Gets wrapped in FlexiPaneItem
    e.RequestedContent = new TextBlock();   // Gets wrapped in FlexiPaneItem
    e.RequestedContent = new FlexiPaneItem(); // Used directly
}

Smart Layout Management

The panel intelligently manages complex layouts:

• Automatic Structure Preservation: When split mode is toggled off, existing split layouts are preserved
• Recursive Split Control: All nested panels automatically inherit split mode settings
• Dynamic Content Loading: Content is created on-demand when panels are split
• Memory Efficient: Only active panels consume resources
• Visual Tree Cleanup: Proper disposal prevents memory leaks and visual tree conflicts
• Template Optimization: Advanced template caching for improved performance

Selection and Focus

The library automatically tracks the selected panel:

// Get the currently selected panel
var selected = flexiPanel.SelectedItem;

// Set selection programmatically
somePane.IsSelected = true;

// Track selection changes
flexiPanel.SelectionChanged += (s, e) => {
    Console.WriteLine($"Selected: {e.NewSelection?.Title}");
};

Minimal Configuration Usage

For the absolute simplest setup:

<flexiPane:FlexiPanel />

The panel will:

• Display helpful instruction text initially
• Activate split functionality when IsSplitModeActive is set to true
• Generate default content automatically if no event handlers are provided
• Handle all split operations seamlessly

🛠️ Requirements

• .NET 9.0 or later
• Windows platform (WPF dependency)
• WPF application project

📚 Documentation

• Architecture Design - System architecture and design principles
• Splitting Mechanism - Detailed splitting algorithms and tree management
• Interactive Features - Mouse overlays, visual guides, and user interaction
• Layout Serialization - Saving and loading panel arrangements

🎮 Demo Application

Check out the FlexiPane.Samples.DefaultApp project for complete working examples:

Simple Demo (MainWindowSimple.xaml)

• ✨ Minimal Setup: Just a ToggleButton and FlexiPanel
• 🎮 Event-Driven Content: Uses unified ContentRequested event
• 🎨 Random Colored Panels: Each panel gets a unique color and timestamp
• 🛡️ Safe Mode Toggling: Toggle split mode on/off without losing panels
• 🔄 Automatic Content Wrapping: Returns simple Border elements that get auto-wrapped

Full-Featured Demo (MainWindow.xaml)

• 🎨 Multiple content types (editor, terminal, explorer)
• 💾 Layout save/load functionality
• 🎛️ Content factory system usage
• ⌨️ Keyboard shortcuts and navigation
• 🎯 Programmatic control APIs

To run the demo:

git clone https://github.com/iyulab/FlexiPane.WPF.git
cd FlexiPane.WPF
dotnet run --project src/FlexiPane.Samples.DefaultApp/

The simple demo shows the minimum code required to get a fully functional split panel system working!

Interactive Split Features in Demo

The demo applications showcase advanced interactive features:

• 🎯 Visual Split Overlays: Hover over panels to see split direction guides
• 🖱️ Mouse-Driven Splitting: Click top/bottom for vertical split, left/right for horizontal split
• 📏 Direction Guides: Visual indicators showing exactly where splits will occur
• 💾 Layout Persistence: Save and restore complex panel arrangements
• ⌨️ Keyboard Shortcuts: ESC to exit split mode, Tab navigation between panels
• 🔄 Smart Close Operations: Close panels with proper visual tree cleanup
• 🎨 Theme Support: Complete XAML styling with modern visual appearance

🤝 Contributing

Contributions are welcome! Please feel free to:

1. 🐛 Report bugs by opening an issue
2. 💡 Suggest features for future versions
3. 🔧 Submit pull requests with improvements
4. 📖 Improve documentation or add examples
5. ⭐ Star the repository if you find it useful!

Please read our contributing guidelines before submitting PRs.

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

⭐ Credits

Developed by iyulab

Built with modern WPF best practices and inspired by proven splitting mechanisms from advanced development environments.

🚀 Release Status

✅ Production Ready - The library is stable and ready for production use. Semantic versioning is followed for all releases.

Current Version: v1.0.1

• ✅ Interactive Split UI: Mouse-driven overlays with visual direction guides
• ✅ Event-Driven Architecture: Unified ContentRequested event system
• ✅ Smart Split Mode: Toggle on/off while preserving existing layouts
• ✅ Advanced Visual Tree Management: Proper disposal and cleanup with modern architecture
• ✅ Layout Serialization: Save/load complex panel arrangements to files
• ✅ Robust Error Handling: Fixed visual tree attachment issues and memory cleanup
• ✅ Comprehensive Demo: Both simple and full-featured examples with layout persistence
• ✅ Zero Configuration: Works out of the box with sensible defaults
• ✅ Accessibility Support: Full keyboard navigation and screen reader compatibility
• ✅ Production Ready: Clean build with zero warnings, comprehensive testing
