EntityFrameworkCore.Doris 0.1.0-alpha.1

EntityFrameworkCore.Doris

EntityFrameworkCore.Doris is a community Entity Framework Core provider for Apache Doris, built on top of the Doris MySQL-compatible protocol through MySqlConnector.

The provider is intentionally OLAP-oriented. It aims to make EF Core useful for Doris table modeling, native Doris DDL, LINQ queries, and append-style writes, while rejecting relational features that do not fit Doris well.

This package is in early alpha. Expect API and translation behavior to evolve.

Getting Started

dotnet add package EntityFrameworkCore.Doris --prerelease

using Microsoft.EntityFrameworkCore;

await using var db = new AnalyticsContext();

var topPages = await db.PageViews
    .Where(v => v.EventDate >= new DateOnly(2026, 1, 1))
    .GroupBy(v => v.Path)
    .Select(g => new { Path = g.Key, Views = g.Count() })
    .OrderByDescending(x => x.Views)
    .Take(10)
    .ToListAsync();

public sealed class AnalyticsContext : DbContext
{
    public DbSet<PageView> PageViews => Set<PageView>();

    protected override void OnConfiguring(DbContextOptionsBuilder optionsBuilder)
        => optionsBuilder.UseDoris(
            "Server=127.0.0.1;Port=9030;Database=analytics;User ID=root;Password=;");

    protected override void OnModelCreating(ModelBuilder modelBuilder)
    {
        modelBuilder.Entity<PageView>(entity =>
        {
            entity.HasKey(e => e.Id);

            entity.HasDuplicateKey(e => new { e.EventDate, e.Path });
            entity.DistributedByHash(e => e.UserId, buckets: 16);
            entity.HasProperties(("replication_num", "1"));
        });
    }
}

public sealed class PageView
{
    public long Id { get; set; }
    public DateOnly EventDate { get; set; }
    public long UserId { get; set; }
    public string Path { get; set; } = "";
    public long Views { get; set; }
}

Doris Table Shape

EntityFrameworkCore.Doris keeps the EF tracking key and the Doris table key separate. Use the normal EF Core key for identity/tracking, then configure the Doris table model explicitly:

modelBuilder.Entity<EventFact>(entity =>
{
    entity.HasKey(e => e.Id);

    entity.HasDuplicateKey(e => new { e.EventDate, e.UserId });
    entity.HasUniqueKey(e => e.Id);
    entity.HasAggregateKey(e => new { e.EventDate, e.UserId });

    entity.DistributedByHash(e => e.UserId, buckets: 32);
    entity.HasProperties(
        ("replication_num", "1"),
        ("enable_unique_key_merge_on_write", "true"));
});

The migration SQL generator emits Doris-native table DDL:

CREATE TABLE `event_facts` (
    ...
)
DUPLICATE KEY(`event_date`, `user_id`)
DISTRIBUTED BY HASH(`user_id`) BUCKETS 32
PROPERTIES(
    "replication_num" = "1"
);

Supported Types

Complex Doris types are not implemented yet.

Current Status

Supported

• UseDoris(...) with connection strings, MySqlConnection, or MySqlDataSource
• LINQ query translation inherited from the current relational/MySQL-based query pipeline, with Doris-specific SQL generation being added incrementally
• LIMIT / OFFSET query pagination
• SaveChanges for INSERT
• Batch insert SQL generation
• EnsureCreated and migrations for native Doris CREATE TABLE
• Doris migration history table generation
• Doris table key, hash distribution, bucket count, and table properties annotations

Explicitly Not Supported

• Change-tracker UPDATE and DELETE
• EF Core schemas; use Doris databases instead
• Foreign keys
• EF unique constraints; use Doris table key configuration instead
• Sequences
• Generated/default/computed columns
• Concurrency tokens
• Navigation, owned, and complex property mapping
• Idempotent migration scripts

Unsupported features throw NotSupportedException early so the provider fails clearly instead of generating OLTP-shaped SQL for Doris.

Migrations

The first migration surface focuses on Doris-native DDL:

dotnet ef migrations add InitialCreate
dotnet ef database update

Generated CREATE TABLE statements include key model, distribution, bucket count, and properties when configured through the fluent API.

Testing

Normal build and unit tests:

dotnet build
dotnet test

Functional tests are skipped by default. To run them against a local Doris FE:

$env:DORIS_RUN_INTEGRATION = "1"
$env:DORIS_TEST_CONNECTION = "Server=127.0.0.1;Port=9030;User ID=root;Password=;"
dotnet test .\test\EFCore.Doris.FunctionalTests\EFCore.Doris.FunctionalTests.csproj

Building Packages

dotnet pack .\src\EFCore.Doris\EFCore.Doris.csproj -c Release -o .\artifacts\packages

The NuGet package id is EntityFrameworkCore.Doris; the assembly and root namespace remain EFCore.Doris.
