EffinitiveFramework.Core 2.0.0

EffinitiveFramework

A high-performance C# web framework designed to outperform FastEndpoints and compete with GenHTTP.

✅ Mission Accomplished:

• 1.11x faster than GenHTTP - Beating another custom HTTP server framework (46.5μs vs 51.7μs)
• 16x faster than FastEndpoints - Delivering on the performance promise (46.5μs vs 739μs)
• 16x faster than ASP.NET Core - Outperforming Microsoft's Minimal API (46.5μs vs 722μs)
• Sub-50μs response times - The fastest C# web framework tested
• 6KB allocations - Minimal memory footprint per request

🚀 Performance Goals

• Zero-allocation routing using Span<T> and Memory<T>
• Minimal overhead for request/response handling
• Optimized hot paths with aggressive inlining
• Efficient memory management using ArrayPool<T>
• Compile-time optimization for endpoint registration

📦 Features

• Simple, intuitive API similar to FastEndpoints
• Type-safe endpoints with generic request/response handling
• Multiple endpoint types - Optimized for sync, async I/O, and streaming operations
  • EndpointBase<TRequest, TResponse> - Synchronous/cached operations (ValueTask)
  • AsyncEndpointBase<TRequest, TResponse> - Async I/O operations (Task)
  • NoRequestEndpointBase<TResponse> - Endpoints without request body (GET, health checks)
  • NoRequestAsyncEndpointBase<TResponse> - Async endpoints without request body
• Server-Sent Events (SSE) - Real-time streaming with three endpoint patterns:
  • NoRequestSseEndpointBase - Simple streaming without request body
  • SseEndpointBase<TRequest> - Streaming with request parsing
  • SseEndpointBase<TRequest, TEventData> - Strongly-typed event streaming
• WebSocket support (RFC 6455) - Full bidirectional messaging with MapWebSocket() or WebSocketEndpointBase
• Static file serving - Zero per-request I/O via in-memory FrozenDictionary cache, 25+ MIME types
• Response compression - Gzip middleware with single-pass serialize+compress pipeline
• Custom HTTP server with direct socket handling for maximum performance
• High-performance transport layer - IOQueue/SocketSenderPool architecture mirroring Kestrel's design
• HTTP/2 support via ALPN negotiation with binary framing and HPACK compression
• HTTP/3 / QUIC (experimental, .NET 10+) - RFC 9114 with QPACK compression, automatic alongside HTTPS
• HTTP/1.1 protocol - Battle-tested and optimized for speed
• TLS/HTTPS support with configurable certificates and modern protocol support
• Minimal allocations in hot code paths
• Benchmark suite included for performance validation

🌐 Protocol Support

• ✅ HTTP/1.1 - Fully supported with custom parser (sub-50μs response times)
• ✅ HTTPS/TLS - Full TLS 1.2/1.3 support with certificate configuration
• ✅ HTTP/2 - Complete implementation with binary framing, HPACK, stream multiplexing, and ALPN
• ✅ HTTP/3/QUIC - Experimental, .NET 10+ only (RFC 9114 with QPACK, automatic when QuicListener.IsSupported)
• ✅ WebSocket - RFC 6455, full framing/fragmentation/ping-pong/close handshake

HTTP/2 Implementation

EffinitiveFramework includes a complete from-scratch HTTP/2 implementation:

• Binary framing layer - All 9 frame types (DATA, HEADERS, SETTINGS, PING, GOAWAY, etc.)
• HPACK compression - Static table (61 entries) + dynamic table + Huffman encoding
• Stream multiplexing - Multiple concurrent requests over single TCP connection
• Flow control - Per-stream and connection-level window management
• ALPN negotiation - Automatic protocol selection during TLS handshake ("h2" or "http/1.1")
• Settings management - Dynamic configuration via SETTINGS frames

HTTP/2 is automatically enabled for HTTPS connections when clients negotiate it via ALPN. See HTTP/2 Implementation Guide for details.

HTTP/3 Implementation (.NET 10+)

When targeting .NET 10 and TLS is configured, EffinitiveFramework starts a QUIC listener on the same HTTPS port:

• RFC 9114 - HTTP/3 framing (DATA, HEADERS, SETTINGS, GOAWAY)
• QPACK compression (RFC 9204) - Header encoding/decoding with static table and encoder/decoder streams
• Control streams - Bidirectional and unidirectional stream management
• Automatic - No extra configuration required; QUIC starts when QuicListener.IsSupported is true

WebSocket Implementation (RFC 6455)

• Full frame support - Text, Binary, Ping, Pong, Close, Continuation frames
• Fragmentation - Multi-frame messages transparently reassembled
• Keep-alive - Automatic Pong replies to client Ping frames
• Close handshake - Graceful connection termination with status codes
• Fluent registration - MapWebSocket(path, handler) or subclass WebSocketEndpointBase

🏗️ Architecture

Core Components

1. EffinitiveApp - Main application bootstrap
2. Router - High-performance routing engine using zero-allocation techniques
3. EndpointBase<TRequest, TResponse> - Base class for synchronous/cached operations (ValueTask)
4. AsyncEndpointBase<TRequest, TResponse> - Base class for I/O operations (Task)
5. IEndpoint - Core endpoint interfaces

Performance Optimizations

• Span-based routing - Routes are matched using ReadOnlySpan<char> to avoid string allocations
• Smart async handling - ValueTask<T> for sync operations, Task<T> for I/O
• Struct types - Key data structures use structs where appropriate
• ArrayPool - Reuses arrays for temporary operations
• Unsafe blocks enabled - Allows for low-level optimizations where needed

📖 Quick Start

1. Create an Endpoint

For simple GET endpoints without request body (use NoRequestEndpointBase):

using EffinitiveFramework.Core;

public class HealthCheckEndpoint : NoRequestEndpointBase<HealthResponse>
{
    protected override string Method => "GET";
    protected override string Route => "/api/health";

    public override ValueTask<HealthResponse> HandleAsync(
        CancellationToken cancellationToken = default)
    {
        return ValueTask.FromResult(new HealthResponse
        {
            Status = "Healthy",
            Timestamp = DateTime.UtcNow,
            Version = "2.0.0"
        });
    }
}

For in-memory/cached operations with request body (use EndpointBase):

using EffinitiveFramework.Core;

public class GetUsersEndpoint : EndpointBase<EmptyRequest, UsersResponse>
{
    protected override string Method => "GET";
    protected override string Route => "/api/users";

    public override ValueTask<UsersResponse> HandleAsync(
        EmptyRequest request,
        CancellationToken cancellationToken = default)
    {
        var users = new List<User>
        {
            new User { Id = 1, Name = "Alice", Email = "alice@example.com" },
            new User { Id = 2, Name = "Bob", Email = "bob@example.com" }
        };

        return ValueTask.FromResult(new UsersResponse { Users = users });
    }
}

For database/I/O operations (use AsyncEndpointBase):

using EffinitiveFramework.Core;

public class CreateUserEndpoint : AsyncEndpointBase<CreateUserRequest, UserResponse>
{
    protected override string Method => "POST";
    protected override string Route => "/api/users";

    public override async Task<UserResponse> HandleAsync(
        CreateUserRequest request,
        CancellationToken cancellationToken = default)
    {
        // True async I/O - database insert
        var user = await _dbContext.Users.AddAsync(new User
        {
            Name = request.Name,
            Email = request.Email
        }, cancellationToken);

        await _dbContext.SaveChangesAsync(cancellationToken);

        return new UserResponse { User = user, Success = true };
    }
}

For real-time Server-Sent Events streaming (use SSE endpoints):

using EffinitiveFramework.Core.Http.ServerSentEvents;

public class ServerTimeEndpoint : NoRequestSseEndpointBase
{
    protected override string Method => "GET";
    protected override string Route => "/api/stream/time";

    protected override async Task HandleStreamAsync(
        SseStream stream,
        CancellationToken cancellationToken)
    {
        // Start automatic keep-alive pings
        _ = stream.StartKeepAliveAsync(TimeSpan.FromSeconds(15), cancellationToken);

        await stream.WriteAsync("connected", "Server time stream started");

        while (!cancellationToken.IsCancellationRequested)
        {
            var timeData = new { Time = DateTime.UtcNow, Zone = "UTC" };
            await stream.WriteJsonAsync(timeData, cancellationToken);
            await Task.Delay(1000, cancellationToken);
        }
    }
}

Define your DTOs:

public record UsersResponse
{
    public List<User> Users { get; init; } = new();
}

public record User
{
    public int Id { get; init; }
    public string Name { get; init; } = string.Empty;
    public string Email { get; init; } = string.Empty;
}

💡 See Endpoint Selection Guide for detailed guidance on choosing between EndpointBase and AsyncEndpointBase

For WebSocket connections (use MapWebSocket or subclass WebSocketEndpointBase):

using EffinitiveFramework.Core.WebSocket;

// Inline handler
app.MapWebSocket("/ws/echo", async (conn, ct) =>
{
    while (conn.IsOpen)
    {
        var msg = await conn.ReceiveAsync(ct);
        if (msg == null) break;
        await conn.SendAsync(msg.Value.Data, msg.Value.Type, ct);
    }
});

// Class-based handler
public class EchoEndpoint : WebSocketEndpointBase
{
    public override string Route => "/ws/echo";

    public override async Task OnConnectedAsync(
        WebSocketConnection connection, CancellationToken cancellationToken)
    {
        while (connection.IsOpen)
        {
            var msg = await connection.ReceiveAsync(cancellationToken);
            if (msg == null) break;
            await connection.SendAsync(msg.Value.Data, msg.Value.Type, cancellationToken);
        }
    }
}

2. Bootstrap the Application

using EffinitiveFramework.Core;

var cts = new CancellationTokenSource();
Console.CancelKeyPress += (s, e) => { e.Cancel = true; cts.Cancel(); };

// Create the app, configure ports, TLS, services and endpoints, then build
var app = EffinitiveApp
    .Create()
    .UsePort(5000)           // HTTP on port 5000
    .UseHttpsPort(5001)      // HTTPS on port 5001 (HTTP/2 + HTTP/3 via ALPN/QUIC)
    .ConfigureTls(tls =>
    {
        tls.CertificatePath = "localhost.pfx";
        tls.CertificatePassword = "dev-password";
    })
    .UseResponseCompression()            // Enable gzip for supported clients
    .UseStaticFiles("wwwroot")           // Serve files from ./wwwroot at /static
    .MapWebSocket("/ws", async (conn, ct) =>   // WebSocket endpoint
    {
        while (conn.IsOpen)
        {
            var msg = await conn.ReceiveAsync(ct);
            if (msg != null) await conn.SendAsync(msg.Value.Data, msg.Value.Type, ct);
        }
    })
    .MapEndpoints() // Automatically discovers and registers all endpoints
    .Build();

// Run the server until cancelled
await app.RunAsync(cts.Token);

Dependency Injection (Configure services)

EffinitiveFramework exposes a light-weight DI integration via ConfigureServices on the builder. Use it to register DbContexts, services and middleware dependencies.

var app = EffinitiveApp.Create()
    .ConfigureServices(services =>
    {
        // Register a scoped EF Core DbContext
        services.AddScoped<AppDbContext>(sp =>
        {
            var options = new DbContextOptionsBuilder<AppDbContext>()
                .UseSqlite("Data Source=products.db")
                .Options;
            return new AppDbContext(options);
        });

        // Register application services
        services.AddScoped<IProductService, ProductService>();
        services.AddScoped<IOrderService, OrderService>();
    })
    .MapEndpoints(typeof(Program).Assembly)
    .Build();

// Resolve a scope for initialization or background work
using var scope = ((EffinitiveFramework.Core.DependencyInjection.ServiceProvider)app.Services!).CreateScope();
var ctx = scope.ServiceProvider.GetService<AppDbContext>();

3. Run the Application

dotnet run --project samples/EffinitiveFramework.Sample

The API will be available at http://localhost:5000 (or as configured).

🧪 Running Benchmarks

dotnet run --project benchmarks/EffinitiveFramework.Benchmarks -c Release

The benchmark suite compares:

• Route matching performance
• Endpoint invocation overhead
• Memory allocations
• Request/response throughput

🎯 Benchmark Results

Framework Comparison (HTTP End-to-End)

Key Performance Metrics

✅ Fastest C# web framework tested
✅ 1.23-1.27x faster than GenHTTP (another custom HTTP server)
✅ ~16x faster than FastEndpoints and ASP.NET Core Minimal API
✅ Sub-50μs response times for both GET and POST
✅ 4.5-5.5 KB memory per request (minimal allocations)

See BENCHMARK_RESULTS.md for detailed results and analysis.

📚 Project Structure

EffinitiveFramework/
├── src/
│   └── EffinitiveFramework.Core/       # Core framework library
│       ├── EffinitiveApp.cs             # Main application class + fluent builder
│       ├── Router.cs                    # High-performance router (FrozenDictionary)
│       ├── EndpointBase.cs              # Base endpoint classes
│       ├── IEndpoint.cs                 # Endpoint interfaces
│       ├── Http/                        # HTTP/1.1 parsing and response writing
│       ├── Http2/                       # HTTP/2 framing, HPACK, stream multiplexing
│       ├── Http3/                       # HTTP/3 / QUIC + QPACK (.NET 10+ only)
│       ├── WebSocket/                   # RFC 6455 WebSocket framing and endpoints
│       ├── StaticFiles/                 # In-memory static file handler
│       ├── Transport/                   # IOQueue, SocketSenderPool, DuplexPipe
│       ├── Middleware/                  # Pipeline + ResponseCompressionMiddleware
│       ├── Authentication/              # JWT, API Key, custom auth handlers
│       ├── Authorization/               # [Authorize], [AllowAnonymous] attributes
│       ├── DependencyInjection/         # ServiceCollection + ServiceProvider
│       └── Configuration/              # ServerOptions, TlsOptions
├── samples/
│   └── EffinitiveFramework.Sample/      # Sample API project
│       ├── Program.cs                   # Application entry point
│       └── Endpoints/                   # Example endpoints
├── benchmarks/
│   └── EffinitiveFramework.Benchmarks/  # Performance benchmarks (BenchmarkDotNet)
└── tests/
    └── EffinitiveFramework.Tests/       # Unit tests

🔧 Development

Prerequisites

• .NET 8 SDK or later (.NET 10 SDK for HTTP/3 support)
• Visual Studio 2022 / VS Code / Rider

Build

dotnet build

Run Tests

dotnet test

Run Sample

dotnet run --project samples/EffinitiveFramework.Sample

🎨 Design Principles

1. Performance First - Every feature is evaluated for its performance impact
2. Zero Allocations - Hot paths should allocate as little as possible
3. Simple API - Easy to use, hard to misuse
4. Type Safety - Leverage C# type system for compile-time guarantees
5. Minimal Dependencies - Only depend on ASP.NET Core fundamentals

🔬 Performance Techniques Used

• Span<T> and Memory<T> - For zero-copy string operations
• ArrayPool<T> - For temporary buffer allocations
• ValueTask<T> - For reduced async allocations
• Aggressive Inlining - [MethodImpl(MethodImplOptions.AggressiveInlining)]
• Struct Types - Value types for small, frequently-used data
• Unsafe Code - Low-level optimizations where beneficial

🆕 What's New in v2.0.0

See RELEASE_NOTES_v2.0.0.md for the full release notes and CHANGELOG.md for the complete version history.

📊 Comparison with FastEndpoints

🚧 Roadmap

• Route parameter extraction (e.g., /users/{id}) ✅ IMPLEMENTED
• Query string binding ✅ IMPLEMENTED (API Key auth)
• Header/cookie binding ✅ IMPLEMENTED (Auth handlers)
• Request validation ✅ IMPLEMENTED (Routya.ResultKit integration)
• Middleware pipeline ✅ IMPLEMENTED (High-performance pipeline)
• Dependency injection integration ✅ IMPLEMENTED (Full DI support)
• Server-Sent Events (SSE) ✅ IMPLEMENTED v1.1.0 (Real-time streaming)
• Response compression (gzip) ✅ IMPLEMENTED v2.0.0 (Single-pass serialize+compress)
• WebSocket support ✅ IMPLEMENTED v2.0.0 (RFC 6455, full framing)
• Static file serving ✅ IMPLEMENTED v2.0.0 (Zero per-request I/O)
• HTTP/3 / QUIC protocol ✅ IMPLEMENTED v2.0.0 (Experimental, .NET 10+)
• Response caching
• OpenAPI/Swagger integration
• Rate limiting

🤝 Contributing

Contributions are welcome! Please ensure:

• All benchmarks pass with improved or comparable performance
• Code follows existing patterns
• Tests are included for new features
• Performance-critical code includes comments explaining optimizations

📄 License

MIT License - see LICENSE file for details

🙏 Acknowledgments

• Inspired by FastEndpoints
• Performance techniques from GenHTTP
• Built on ASP.NET Core

Note: This is a performance-focused framework. Always benchmark your specific use case to ensure it meets your requirements.
