EasyOcrSharp 2.2.1

<div align="center"> <img src="src/EasyOcrSharp/Assets/icon.gif" alt="EasyOcrSharp Logo" width="128" height="128"> <h1>EasyOcrSharp</h1>

High-accuracy, fully-offline OCR for .NET — EasyOCR's neural models running natively on ONNX Runtime. No Python.

</div>

EasyOcrSharp runs EasyOCR's exact CRAFT text detector and CRNN recognizers, exported to ONNX, through Microsoft.ML.OnnxRuntime. You get EasyOCR-grade accuracy in a tiny managed package — no Python interpreter, no PyTorch, no native OCR binaries, and nothing leaves the machine.

Table of contents

• Installation
• Quick start
• The result model
• Input sources
• Recognition options
• Region of interest
• Multiple languages
• Automatic language detection
• Scanned-document preprocessing
• PDF input & searchable PDF
• Output formats (hOCR / ALTO / TSV / JSON)
• Constrained fields (allow/block-lists & detection thresholds)
• Decoders, rotation & batching
• Recognize from known boxes
• Custom recognizers
• Fine-tuning grouping & contrast
• Quantized models
• Detection-only & visualization
• Batch processing
• Observability & health checks
• Dependency injection
• GPU & execution providers
• Resilient & offline model downloads
• Supported languages
• How model downloads work
• Accuracy notes
• Building & testing
• License

Installation

dotnet add package EasyOcrSharp

PDF input and searchable-PDF output are built in — no extra package.

For NVIDIA GPU acceleration (Windows/Linux x64, CUDA 12+):

dotnet add package EasyOcrSharp.Gpu

Upgrading from 1.x? v2 replaced the ~1.5 GB embedded Python+PyTorch runtime with native ONNX. The public API (EasyOcrService, OcrResult, OcrLine, OcrBoundingBox) is unchanged.

Quick start

using EasyOcrSharp.Services;

await using var ocr = new EasyOcrService();

var result = await ocr.ExtractTextFromImage("sample.png", new[] { "en" });

Console.WriteLine(result.FullText);

foreach (var line in result.Lines)
    Console.WriteLine($"{line.Text}  (confidence {line.Confidence:P0})");

The first call for a language downloads its model (cached afterwards). Detected text is returned as reading-order lines (top-to-bottom), matching EasyOCR's readtext().

The result model

public sealed record OcrResult
{
    public string FullText { get; }                 // all lines joined by newlines
    public IReadOnlyList<OcrLine> Lines { get; }
    public IReadOnlyList<string> Languages { get; }
    public TimeSpan Duration { get; }
    public bool UsedGpu { get; }
}

public sealed record OcrLine
{
    public string Text { get; }
    public double Confidence { get; }                       // 0..1
    public IReadOnlyList<OcrPoint> BoundingPolygon { get; } // 4 corners
    public OcrBoundingBox BoundingBox { get; }              // MinX/MinY/MaxX/MaxY + Width/Height/Center
}

Input sources

OCR from a file path, a Stream, raw encoded bytes, or an already-decoded ImageSharp image:

await ocr.ExtractTextFromImage("photo.jpg",            new[] { "en" });
await ocr.ExtractTextFromImage(stream,                  new[] { "en" });
await ocr.ExtractTextFromImage(File.ReadAllBytes("p"),  new[] { "en" });   // byte[]
await ocr.ExtractTextFromImage(memory,                  new[] { "en" });   // ReadOnlyMemory<byte>
await ocr.ExtractTextFromImage(image,                   new[] { "en" });   // Image<Rgb24> (caller-owned)

All overloads accept an optional RecognitionOptions and a CancellationToken.

Recognition options

var options = new RecognitionOptions
{
    Grouping = TextGrouping.Line,    // Word | Line (default) | Paragraph
    MinConfidence = 0.3,             // drop results below this confidence
    MaxDegreeOfParallelism = 8,      // regions recognized concurrently (default: CPU count)
    AdjustContrast = true,           // low-confidence contrast-retry pass (EasyOCR's 2nd pass)
    Region = null,                   // optional region of interest (see below)
};

var result = await ocr.ExtractTextFromImage("doc.png", new[] { "en" }, options);

Region of interest

Restrict OCR to a rectangle — ideal for a fixed field (price, license plate, banner) and faster than scanning the whole image. Boxes are always reported in the original image's coordinates.

// Absolute pixels:
var roi = new RecognitionOptions { Region = OcrRegion.Pixels(x: 40, y: 320, width: 500, height: 80) };

// Resolution-independent fractions — e.g. the bottom third:
var bottom = new RecognitionOptions { Region = OcrRegion.Fraction(0, 0.66, 1, 0.34) };

var result = await ocr.ExtractTextFromImage("receipt.png", new[] { "en" }, bottom);

Multiple languages

Pass several codes for mixed-script images — each region is read by every requested script pack and the highest-confidence result wins:

var result = await ocr.ExtractTextFromImage("street_sign.png", new[] { "en", "ch_sim", "ru" });

Each additional script family loads its own model, so request only the scripts you expect.

Automatic language detection

Don't know the language? Let the engine detect it — pass no codes and set AutoDetectLanguage:

var result = await ocr.ExtractTextFromImage("unknown.png", Array.Empty<string>(),
    new RecognitionOptions { AutoDetectLanguage = true });

// Or just detect, without recognizing:
IReadOnlyList<string> langs = await ocr.DetectLanguagesAsync("unknown.png");

Detection samples the largest text regions and scores candidate script packs by confidence. Candidates default to a common set (Latin, Cyrillic, Chinese, Japanese, Korean); widen them when you expect heavier scripts:

var opts = new RecognitionOptions
{
    AutoDetectLanguage = true,
    AutoDetectCandidates = new[] { "en", "ar", "hi", "ch_sim" },
};

Scanned-document preprocessing

For photos and scans, enable clean-up via RecognitionOptions.Preprocessing:

var opts = new RecognitionOptions
{
    Preprocessing = new PreprocessingOptions
    {
        Deskew = true,            // straighten small tilt (±15°)
        DetectOrientation = true, // fix 90°/180°/270° rotation (≈4× cost)
        Binarize = true,          // adaptive black/white for uneven lighting
        Denoise = true,           // suppress scanner speckle
    },
};
var result = await ocr.ExtractTextFromImage("scan.jpg", new[] { "en" }, opts);

When Deskew or DetectOrientation rotate the image, bounding boxes are reported in the corrected image's coordinate space.

PDF input & searchable PDF

OCR scanned PDFs and emit searchable PDFs — built into the main package (no extra install needed). Pages are rasterized with PDFium and processed one at a time, so memory stays low even on large documents.

using EasyOcrSharp.Pdf;

await using var ocr = new EasyOcrService();

// 1) Extract text from every page:
PdfOcrResult doc = await ocr.ExtractTextFromPdfAsync("scan.pdf", new[] { "en" });
Console.WriteLine(doc.FullText);
foreach (var page in doc.Pages)
    Console.WriteLine($"Page {page.PageNumber}: {page.Ocr.Lines.Count} lines");

// 2) Produce a searchable PDF (original pages + invisible, selectable text layer):
await ocr.CreateSearchablePdfAsync("scan.pdf", "scan.searchable.pdf", new[] { "en" },
    pdfOptions: new PdfOcrOptions { Dpi = 250, JpegQuality = 80 });

PdfOcrOptions controls render Dpi, searchable-PDF JpegQuality, and a per-page Progress callback. The searchable text layer is best for Latin scripts (base-14 font, WinAnsi encoding).

Output formats (hOCR / ALTO / TSV / JSON)

Any OcrResult converts to the interchange formats DMS and archival pipelines expect:

using EasyOcrSharp.Export;

using var img = Image.Load<Rgb24>("page.png");
var result = await ocr.ExtractTextFromImage(img, new[] { "en" });

string hocr = result.ToHocr(pageWidth: img.Width, pageHeight: img.Height); // hOCR (HTML)
string alto = result.ToAlto(pageWidth: img.Width, pageHeight: img.Height); // ALTO XML v4
string tsv  = result.ToTsv();                                              // Tesseract-style TSV
string json = result.ToJson(indented: true);                              // AOT-safe JSON

ToJson uses a source-generated EasyOcrJsonContext, so it works in trimmed / Native-AOT apps with no reflection warnings.

Constrained fields (allow/block-lists & detection thresholds)

For fixed-format fields, restrict the character set — this sharply cuts errors:

// Digits only (invoice totals, IDs, meter readings):
var digits = new RecognitionOptions { Allowlist = "0123456789.," };

// License plate (upper-case + digits):
var plate = new RecognitionOptions { Allowlist = "ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789-" };

var total = await ocr.ExtractTextFromImage("receipt.png", new[] { "en" }, digits);

Use Blocklist to forbid specific characters instead. For hard inputs, the CRAFT detector thresholds are exposed via RecognitionOptions.Detection (defaults match EasyOCR):

var opts = new RecognitionOptions
{
    Detection = new DetectionOptions
    {
        TextThreshold = 0.6,  // lower → catch fainter text
        LowText = 0.3,        // lower → keep more of each glyph
        MagRatio = 1.5,       // enlarge before detection (small text)
    },
};

Decoders, rotation & batching

Switch the CTC decoder, recognize rotated text, or batch boxes through the model — all via RecognitionOptions (every option defaults to the previous behaviour):

var opts = new RecognitionOptions
{
    Decoder = DecoderType.BeamSearch,  // Greedy (default) | BeamSearch | WordBeamSearch
    BeamWidth = 10,                    // explored hypotheses (beam decoders)
    RotationInfo = new[] { 90, 270 },  // also try each box rotated; keep the best reading
    BatchSize = 16,                    // batch boxes through one ONNX run (see note below)
};

var result = await ocr.ExtractTextFromImage("rotated_labels.png", new[] { "en" }, opts);

BatchSize note. Batching needs a batch-capable recognizer export; the currently hosted models are exported with batch fixed at 1, so BatchSize > 1 transparently falls back to per-box inference today (results are unaffected). Per-box recognition already runs concurrently — tune throughput with MaxDegreeOfParallelism.

WordBeamSearch constrains output to a lexicon you supply, which is powerful for closed vocabularies (part numbers, place names, a product catalogue):

var opts = new RecognitionOptions
{
    Decoder = DecoderType.WordBeamSearch,
    Dictionary = new[] { "INVOICE", "TOTAL", "SUBTOTAL", "TAX" },
};

Recognize from known boxes

If you already have regions — from DetectRegionsAsync, a previous run, or your own layout analysis — recognize them directly and skip detection (EasyOCR's recognize()):

using var image = Image.Load<Rgb24>("form.png");

// e.g. reuse a detection pass, or pass your own polygons (pixel coordinates):
IReadOnlyList<DetectedRegion> regions = await ocr.DetectRegionsAsync(image);

OcrResult result = await ocr.RecognizeRegionsAsync(image, regions, new[] { "en" });

There's also an overload taking raw polygons (IEnumerable<IReadOnlyList<OcrPoint>>).

Custom recognizers

Register your own exported CRNN ONNX model (e.g. a fine-tuned EasyOCR recog_network) for chosen language codes. A custom recognizer takes precedence over the built-in pack and is loaded straight from disk — never downloaded:

var options = new EasyOcrServiceOptions();
options.CustomRecognizers.Add(new CustomRecognizer
{
    Name = "my_meter_reader",
    ModelPath = @"D:\models\meter_g2.onnx",
    VocabPath = @"D:\models\meter_g2.vocab.json", // or set Characters = "0123456789." inline
    Languages = new[] { "en" },                    // claim the codes it should handle
});

await using var ocr = new EasyOcrService(options);

Fine-tuning grouping & contrast

The thresholds that merge boxes into lines/paragraphs and trigger the contrast-retry pass are exposed for difficult layouts (defaults reproduce EasyOCR's behaviour):

var opts = new RecognitionOptions
{
    GroupingOptions = new GroupingOptions
    {
        SlopeThreshold = 0.1,        // tolerate gently tilted lines (slope_ths)
        YCenterThreshold = 0.5,      // vertical tolerance for same-line boxes (ycenter_ths)
        WidthThreshold = 1.0,        // max horizontal gap to merge on a line (width_ths)
        ParagraphYThreshold = 1.0,   // vertical reach when forming paragraphs (y_ths)
    },
    ContrastThreshold = 0.1,         // re-recognize below this confidence (contrast_ths)
    AdjustContrastTarget = 0.5,      // grey-stretch target for the retry pass (adjust_contrast)
};

Quantized models

Set Quantize to fetch the int8-quantized recognizers instead of the float ones — EasyOCR's quantize=True, for smaller downloads:

await using var ocr = new EasyOcrService(new EasyOcrServiceOptions { Quantize = true });

The int8 variants are hosted alongside the float models and SHA256-verified on download, and text output is effectively unchanged. The win is vocabulary-dependent: ONNX Runtime (CPU) int8-quantizes the matmul/linear layers but not the BiLSTM/convolutions, so large-vocabulary packs shrink most (e.g. zh_sim ~22 → ~16 MB) while small-vocabulary packs change little. The detector stays float (as in EasyOCR). Opt-in; the float models are the default.

Detection-only & visualization

Locate text regions without recognizing them — fast and language-independent, ideal for layout analysis, redaction, or cropping fields before a targeted recognition pass:

IReadOnlyList<DetectedRegion> regions = await ocr.DetectRegionsAsync("form.png");

Draw the boxes onto a copy of the image for debugging (no extra dependency; original is untouched):

using EasyOcrSharp.Export;

using var img = Image.Load<Rgb24>("page.png");
var result = await ocr.ExtractTextFromImage(img, new[] { "en" });
using var annotated = img.DrawAnnotations(result, new Rgb24(255, 0, 0), thickness: 2);
await annotated.SaveAsPngAsync("page.annotated.png");

Batch processing

Process a folder or queue with bounded concurrency. Results stream as they complete; a failed image is captured (not thrown), so one bad file never aborts the batch:

var files = Directory.EnumerateFiles("inbox", "*.png");

await foreach (var item in ocr.ExtractTextFromImagesAsync(files, new[] { "en" }, maxConcurrency: 4))
{
    if (item.Succeeded) Console.WriteLine($"{item.Source}: {item.Result!.Lines.Count} lines");
    else                Console.Error.WriteLine($"{item.Source} failed: {item.Error!.Message}");
}

Observability & health checks

EasyOcrSharp emits OpenTelemetry-ready metrics and traces, always-on with near-zero cost when nobody is listening:

builder.Services.AddOpenTelemetry()
    .WithMetrics(m => m.AddMeter(EasyOcrDiagnostics.MeterName))   // operations, duration, lines, model loads/bytes
    .WithTracing(t => t.AddSource(EasyOcrDiagnostics.ActivitySourceName));

Add a readiness probe that reports whether the models for your languages are cached (so the first real request won't block on a download):

builder.Services.AddHealthChecks()
    .AddEasyOcrHealthCheck(languages: new[] { "en" });

Dependency injection

services.AddEasyOcrSharp(o =>
{
    o.ModelCachePath = "/var/cache/easyocr";
    // GPU is automatic (ExecutionProvider = Auto). To force CPU in a multi-tenant host:
    // o.ExecutionProvider = OcrExecutionProvider.Cpu;
});

public class ReceiptParser(IEasyOcrService ocr) { /* inject anywhere */ }

Registered as a singleton — ONNX sessions are expensive to build and thread-safe to reuse.

GPU & execution providers

GPU is automatic. ExecutionProvider defaults to Auto: on the first run EasyOcrSharp asks ONNX Runtime what accelerators are actually present and uses the best one, falling back to CPU when there's none. You don't pick a provider — you just install the package for the hardware you have:

Why a separate package? The ONNX Runtime variants ship the same onnxruntime.dll compiled with different providers, so only one can be referenced at a time — and the CUDA build is several hundred MB. Shipping it as an opt-in package keeps the base library small and cross-platform; Auto then lights up whatever you installed.

// Nothing to configure — add the EasyOcrSharp.Gpu package and a GPU is used if present.
await using var ocr = new EasyOcrService();

You can still pin a provider explicitly (e.g. to force CPU, or to require CUDA) and set ONNX Runtime thread limits:

await using var ocr = new EasyOcrService(new EasyOcrServiceOptions
{
    ExecutionProvider = OcrExecutionProvider.Cuda, // Auto (default) | Cpu | Cuda | CoreMl
    IntraOpNumThreads = 4,   // cap CPU use in multi-tenant servers (null = runtime default)
});

Any non-CPU provider falls back to CPU automatically (with a logged warning) if its runtime is missing or the device fails to initialize — your app keeps working. The legacy useGpu: true flag still works and forces CUDA. Check ocr.UseGpu to see whether an accelerator was selected.

GPU upgrade hint. When Auto runs on CPU but a real NVIDIA GPU is physically present, EasyOcrSharp detects it and tells you the exact package to add — EasyOcrSharp.Gpu — so there's no guessing. The message is logged once at startup and also exposed:

await using var ocr = new EasyOcrService();
if (ocr.GpuAccelerationHint is { } hint) Console.WriteLine(hint);
// e.g. "EasyOcrSharp: an NVIDIA GPU was detected but OCR is running on CPU. Install the
//       'EasyOcrSharp.Gpu' NuGet package for CUDA acceleration. ..."

(NuGet can't add the package for you at restore time, so the library does the next best thing: detects the hardware at runtime and names the precise package to install. Adding it is the only manual step.)

Resilient & offline model downloads

Model downloads are production-hardened: atomic, SHA256-verified, resumable (HTTP range), and retried with exponential backoff. Tune everything via ModelDownloadOptions:

await using var ocr = new EasyOcrService(new EasyOcrServiceOptions
{
    Download = new ModelDownloadOptions
    {
        MaxRetries = 5,
        Offline = false,                              // true = never download; fail fast if not cached
        BaseUrlOverride = "https://mirror.corp/ocr",  // private mirror
        HttpClientFactory = () => httpClientFactory.CreateClient("ocr"), // proxy / corporate certs
        Progress = new Progress<ModelDownloadProgress>(p =>
            Console.WriteLine($"{p.FileName}: {p.Fraction:P0}")),
    },
});

For air-gapped deployments, pre-seed the cache and set Offline = true — a missing model then throws a clear error instead of attempting a download.

Supported languages

Languages are grouped by script; one recognizer covers an entire group, so ["en","es","fr"] loads a single model. Pack sizes vary widely with the network each script was trained on — some are a few MB, some ~210 MB — which affects first-run download size only, not runtime behaviour.

That's all 86 languages EasyOCR supports, mapped exactly to the model each was trained on.

Not supported: Greek (el) and Hebrew (he) — upstream EasyOCR ships no model for either script, so they cannot be exported.

How model downloads work

EasyOcrSharp ships no models in the NuGet package. On the first call for a language it downloads, into a local cache:

1. CRAFT detector (craft_mlt_25k.onnx, ~80 MB) — shared by all languages, downloaded once.
2. CRNN recognizer for the language's script pack (e.g. latin_g2.onnx).
3. A small vocabulary sidecar (<pack>.vocab.json).

Every file is SHA256-verified against a checksum baked into the library, so corrupted or tampered downloads are rejected. Models are hosted on Hugging Face.

Default cache: %LOCALAPPDATA%\EasyOcrSharp\models (Windows) or the platform equivalent. Override it:

await using var ocr = new EasyOcrService(modelCachePath: @"D:\MyApp\Models");

EASYOCRSHARP_CACHE=/var/cache/easyocr                          # cache directory
EASYOCRSHARP_MODEL_BASE_URL=https://files.mycorp.example/ocr   # private/offline mirror

Offline / air-gapped: pre-seed your cache directory with the .onnx + .vocab.json files from the model repo — no network is needed at runtime.

Accuracy notes

EasyOcrSharp reproduces EasyOCR's pipeline faithfully — aspect-preserving resize, normalization, a low-confidence contrast-retry pass, CRAFT box dilation, perspective de-warping of rotated text, and CTC decoding (greedy by default, with optional beam / word-beam search) — so output matches upstream EasyOCR. As with any OCR:

• Visually identical glyphs (capital I vs lowercase l, $ vs 8) can be confused.
• Handwriting and low-resolution / low-contrast text are harder than clean printed text.
• Right-to-left scripts (Arabic) are returned in the model's character order.

Building & testing

git clone https://github.com/easyocrsharp/EasyOcrSharp.git
cd EasyOcrSharp
dotnet build -c Release

# Everything — unit + real end-to-end integration tests. Downloads the models on first run
# and reports a pass/fail summary:
dotnet test

# Fast unit tests only (no models, no network):
dotnet test --filter "Category!=Integration"

# Only the model-backed integration tests:
dotnet test --filter "Category=Integration"

# Interactive console demo:
dotnet run --project test/EasyOcrSharp.Demo

The integration tests exercise every feature against the real engine (allow/block-lists, detection-only, exporters, batch, metrics/tracing, health check, execution-provider fallback, and the full PDF pipeline) — no mocks. The PDF tests need two small fixtures you generate yourself; they're skipped (never failed) until present. See test/assets/pdf/README.md for the exact one-page and three-page PDFs to drop in.

CI (GitHub Actions) builds and runs the unit tests on Linux and Windows for every push and PR. See CHANGELOG.md for release history.

License

MIT — see LICENSE. EasyOCR (the upstream model authors) is also MIT-licensed.

Acknowledgments

• EasyOCR — the underlying CRAFT + CRNN models
• ONNX Runtime — neural network execution
• SixLabors.ImageSharp — image I/O and resizing
