Caching 5.1.2

Caching

<img src="https://github.com/jchristn/Caching/raw/main/assets/icon.png" height="128" width="128">

High-performance, thread-safe caching library for .NET with FIFO and LRU eviction policies, automatic expiration, persistence support, and comprehensive event notifications.

What Is This Library?

Caching is a lightweight, production-ready caching library that provides:

• FIFO (First-In-First-Out) Cache: Evicts the oldest entries when capacity is reached
• LRU (Least Recently Used) Cache: Evicts the least recently accessed entries
• Thread-Safe: All operations are fully thread-safe for concurrent access
• Automatic Expiration: Time-based expiration with sliding or absolute TTL
• Event Notifications: Comprehensive events for cache operations
• Persistence Layer: Optional persistence to disk or custom storage
• Statistics Tracking: Built-in hit/miss rates, eviction counts, and performance metrics
• Memory Limits: Optional memory-based eviction in addition to count-based
• Modern API: GetOrAdd, AddOrUpdate, and async-ready patterns

Installation

dotnet add package Caching

Or via Package Manager:

Install-Package Caching

Current Release

The current package version is 5.1.2. This patch makes every Try* method (TryGet, TryAddReplace, TryGetOrAdd, TryRemove) return false instead of throwing for any failure, including null keys, value factory exceptions, and persistence driver exceptions; only ObjectDisposedException is thrown after disposal. Version 5.1.1 keeps the expiration task running after persistence or Expired handler failures, stops synchronous GetOrAdd/AddOrUpdate from running factories, persistence, and event handlers under the cache lock, and makes ExpirationIntervalMs changes take effect immediately. Version 5.1.0 added built-in observability: metrics and traces through the standard .NET Meter and ActivitySource APIs (both named Caching), ready for Prometheus, Tempo, Grafana, or any OTLP backend. See Telemetry and TELEMETRY.md.

Quick Start

Basic FIFO Cache

using Caching;

// Create a FIFO cache with capacity of 1000, evicting 100 items when full
var cache = new FIFOCache<string, Person>(capacity: 1000, evictCount: 100);

// Add items
cache.AddReplace("user:123", new Person { Name = "Alice", Age = 30 });

// Get items
Person person = cache.Get("user:123");

// Try pattern (no exceptions)
if (cache.TryGet("user:123", out Person p))
{
    Console.WriteLine($"Found: {p.Name}");
}

// Remove items
cache.Remove("user:123");

// Dispose when done
cache.Dispose();

Basic LRU Cache

// LRU evicts least recently accessed items
var cache = new LRUCache<string, byte[]>(capacity: 500, evictCount: 50);

cache.AddReplace("image:1", imageBytes);
cache.Get("image:1"); // Updates last-used timestamp

cache.Dispose();

Key Features

1. Expiration

Absolute Expiration

// Expires at specific time
cache.AddReplace("session:xyz", sessionData, DateTime.UtcNow.AddMinutes(30));

// Or use TimeSpan for relative expiration
cache.AddReplace("temp:data", tempData, TimeSpan.FromSeconds(60));

Sliding Expiration

// Enable sliding expiration (TTL refreshes on access)
cache.SlidingExpiration = true;

cache.AddReplace("sliding:key", value, TimeSpan.FromMinutes(5));
// Each time you access the item, expiration resets to 5 minutes from now
cache.Get("sliding:key"); // Refreshes expiration

2. GetOrAdd Pattern

// Atomically get existing or create new value
var person = cache.GetOrAdd("user:456", key =>
{
    // This factory only runs if key doesn't exist
    return database.GetPerson(456);
});

// With expiration
var data = cache.GetOrAdd("data:789",
    key => LoadExpensiveData(key),
    TimeSpan.FromHours(1));

3. AddOrUpdate Pattern

// Add if new, update if exists
var result = cache.AddOrUpdate(
    "counter:visits",
    addValue: 1,
    updateValueFactory: (key, oldValue) => oldValue + 1);

Console.WriteLine($"Visit count: {result}");

4. Events

cache.Events.Added += (sender, e) => Console.WriteLine($"Added: {e.Key}");

cache.Events.Replaced += (sender, e) => Console.WriteLine($"Replaced: {e.Key}");

cache.Events.Removed += (sender, e) => Console.WriteLine($"Removed: {e.Key}");

cache.Events.Evicted += (sender, keys) => Console.WriteLine($"Evicted {keys.Count} items");

cache.Events.Expired += (sender, key) => Console.WriteLine($"Expired: {key}");

cache.Events.Cleared += (sender, e) => Console.WriteLine("Cache cleared");

cache.Events.Disposed += (sender, e) => Console.WriteLine("Cache disposed");

5. Persistence

Implement the IPersistenceDriver<TKey, TValue> interface (all methods are async):

public class FilePersistence : IPersistenceDriver<string, string>
{
    private readonly string _directory;

    public FilePersistence(string directory)
    {
        _directory = directory;
        Directory.CreateDirectory(directory);
    }

    public async Task WriteAsync(string key, string data, CancellationToken ct = default)
    {
        await File.WriteAllTextAsync(Path.Combine(_directory, key), data, ct);
    }

    public async Task<string> GetAsync(string key, CancellationToken ct = default)
    {
        return await File.ReadAllTextAsync(Path.Combine(_directory, key), ct);
    }

    public async Task DeleteAsync(string key, CancellationToken ct = default)
    {
        await Task.Run(() => File.Delete(Path.Combine(_directory, key)), ct);
    }

    public async Task ClearAsync(CancellationToken ct = default)
    {
        foreach (var file in Directory.GetFiles(_directory))
            await Task.Run(() => File.Delete(file), ct);
    }

    public async Task<bool> ExistsAsync(string key, CancellationToken ct = default)
    {
        return await Task.Run(() => File.Exists(Path.Combine(_directory, key)), ct);
    }

    public async Task<List<string>> EnumerateAsync(CancellationToken ct = default)
    {
        return await Task.Run(() => Directory.GetFiles(_directory)
            .Select(Path.GetFileName)
            .ToList(), ct);
    }
}

// Use with cache
var persistence = new FilePersistence("./cache_data");
var cache = new LRUCache<string, string>(1000, 100, persistence);

// Restore from persistence on startup
await cache.PrepopulateAsync();

// All add/remove operations automatically persist
await cache.AddReplaceAsync("key", "value"); // Written to disk
await cache.RemoveAsync("key");              // Deleted from disk

// Sync methods also available (block on async internally)
cache.AddReplace("key2", "value2");
cache.Remove("key2");

6. Statistics

var cache = new FIFOCache<string, object>(1000, 100);

// Perform operations
cache.AddReplace("key1", "value1");
cache.Get("key1");        // Hit
cache.TryGet("missing", out _); // Miss

// Get statistics
var stats = cache.GetStatistics();

Console.WriteLine($"Hit Rate: {stats.HitRate:P}");
Console.WriteLine($"Hits: {stats.HitCount}");
Console.WriteLine($"Misses: {stats.MissCount}");
Console.WriteLine($"Evictions: {stats.EvictionCount}");
Console.WriteLine($"Expirations: {stats.ExpirationCount}");
Console.WriteLine($"Current Count: {stats.CurrentCount}");
Console.WriteLine($"Capacity: {stats.Capacity}");

// Reset counters
cache.ResetStatistics();

7. Memory Limits

var cache = new FIFOCache<string, byte[]>(10000, 100);

// Limit cache to 100MB
cache.MaxMemoryBytes = 100 * 1024 * 1024;

// Provide size estimator for your value type
cache.SizeEstimator = bytes => bytes.Length;

// Cache will evict entries if memory limit is exceeded
cache.AddReplace("large", new byte[10 * 1024 * 1024]); // 10MB

Console.WriteLine($"Memory used: {cache.CurrentMemoryBytes} bytes");

8. Configuration Options

var cache = new LRUCache<int, string>(1000, 100);

// Sliding expiration
cache.SlidingExpiration = true;

// Expiration check interval (default: 1000ms)
cache.ExpirationIntervalMs = 500;

// Memory limits
cache.MaxMemoryBytes = 50 * 1024 * 1024; // 50MB
cache.SizeEstimator = str => str.Length * 2; // Unicode estimation

9. Telemetry

Every cache emits metrics and traces through the BCL System.Diagnostics.Metrics.Meter and System.Diagnostics.ActivitySource, both named Caching. There is no dependency on OpenTelemetry or any exporter, and the cost is effectively zero until a collector subscribes.

var cache = new LRUCache<string, Product>(10000, 100, persistenceDriver);
cache.Name = "products"; // cache.name label; use a short static value

// In the host, subscribe a collector to the "Caching" meter and activity source, for example with Radiant:
settings.Sources.AddMeter(CacheTelemetryNames.MeterName);
settings.Sources.AddActivitySource(CacheTelemetryNames.ActivitySourceName);

// or with the OpenTelemetry SDK:
// .WithMetrics(m => m.AddMeter("Caching")).WithTracing(t => t.AddSource("Caching"))

What an operator gets:

• Metrics: duration and outcome of every operation, hit/miss counts, evictions by reason, expirations, persistence driver call latency and failures, atomic lock wait time and queue depth, entries/capacity/memory gauges, expiration sweep duration and last-success time, and a build info gauge.
• Traces: a span per mutation (caching add_replace, caching get_or_add, ...) nested under the caller's span, stage:lock_wait and stage:value_factory child spans, a client span per persistence call (persistence write, ...), and a root span per expiration sweep that removed entries.

Per-instance switches live on cache.Telemetry (Enable, EnableMetrics, EnableTraces, TraceLookups, RecordExceptionMessages). Keys and values are never recorded. See TELEMETRY.md for the full metrics and spans catalog, PromQL, alerts, and a suggested dashboard.

API Reference

All Try* methods follow one contract: they return false (with any out value set to default) instead of throwing for every failure, including invalid arguments, value factory exceptions, and persistence driver exceptions. The only exception they throw is ObjectDisposedException after the cache is disposed. Failures are still visible through telemetry. If the persistence driver fails, the in-memory change has already been applied, as with the throwing variant.

Core Methods

Constructors

// Basic cache
new FIFOCache<TKey, TValue>(capacity, evictCount);
new LRUCache<TKey, TValue>(capacity, evictCount);

// With custom key comparer
new FIFOCache<TKey, TValue>(capacity, evictCount, comparer: StringComparer.OrdinalIgnoreCase);

// With persistence
new FIFOCache<TKey, TValue>(capacity, evictCount, persistenceDriver);

// With persistence and custom comparer
new LRUCache<TKey, TValue>(capacity, evictCount, persistenceDriver, comparer);

Properties

Thread Safety

All cache operations are thread-safe and can be called concurrently from multiple threads:

var cache = new LRUCache<int, string>(10000, 100);

// Safe to call from multiple threads
Parallel.For(0, 1000, i =>
{
    cache.AddReplace(i, $"value{i}");
    cache.TryGet(i, out _);
    if (i % 10 == 0) cache.TryRemove(i, out _);
});

Performance Tips

1. Choose the Right Cache Type:

   • Use FIFO when access patterns don't matter (e.g., time-series data)
   • Use LRU when recent items are more likely to be accessed again

2. Set Appropriate Capacity:

   • Monitor HitRate to tune capacity
   • Higher capacity = better hit rate but more memory

3. Tune EvictCount:

   • Larger EvictCount = fewer eviction operations but more items removed at once
   • Smaller EvictCount = more frequent evictions but finer-grained

4. Use TryGet for Optional Lookups:

   • TryGet is faster than catching exceptions from Get

5. Minimize Event Handler Work:

   • Events fire synchronously; keep handlers fast
   • Offload heavy work to background tasks

6. Memory Limits:

   • Only use MaxMemoryBytes if needed; it adds overhead
   • Provide accurate SizeEstimator for best results

Migrating from v4.x to v5.0

v5.0 is a breaking change. Key updates required:

1. Persistence Driver (Async-Only)

// v4.x (sync methods)
public class MyDriver : IPersistenceDriver<string, string>
{
    public void Write(string key, string data) { }
    public string Get(string key) { }
    public void Delete(string key) { }
    public void Clear() { }
    public bool Exists(string key) { }
    public List<string> Enumerate() { }
}

// v5.0 (async methods)
public class MyDriver : IPersistenceDriver<string, string>
{
    public Task WriteAsync(string key, string data, CancellationToken ct = default) { }
    public Task<string> GetAsync(string key, CancellationToken ct = default) { }
    public Task DeleteAsync(string key, CancellationToken ct = default) { }
    public Task ClearAsync(CancellationToken ct = default) { }
    public Task<bool> ExistsAsync(string key, CancellationToken ct = default) { }
    public Task<List<string>> EnumerateAsync(CancellationToken ct = default) { }
}

2. TryRemove Returns Value

// v4.x
bool removed = cache.TryRemove("key");

// v5.0
bool removed = cache.TryRemove("key", out string value);
// or if you don't need the value:
bool removed = cache.TryRemove("key", out _);

3. New Features

// Custom key comparer
var cache = new FIFOCache<string, int>(100, 10,
    comparer: StringComparer.OrdinalIgnoreCase);

// GetOrDefault (doesn't throw)
string value = cache.GetOrDefault("missing", "fallback");

// Async methods
await cache.AddReplaceAsync("key", "value");
var result = await cache.GetOrAddAsync("key", async k => await FetchAsync(k));
await cache.PrepopulateAsync();

Migrating from v3.x to v4.0

// v3.x
cache.Events.Added = handler; // Overwrites all handlers! ❌

// v4.0+
cache.Events.Added += handler; // Adds handler ✅

Contributing

Contributions are welcome! Please open an issue or PR on GitHub.

License

See LICENSE.md
