Blazorme.Split 26.9.7

.NET 10.0 This package targets .NET 10.0. The package is compatible with this framework or higher.
There is a newer version of this package available.
See the version list below for details.
dotnet add package Blazorme.Split --version 26.9.7






NuGet\Install-Package Blazorme.Split -Version 26.9.7
This command is intended to be used within the Package Manager Console in Visual Studio, as it uses the NuGet module's version of Install-Package.
<PackageReference Include="Blazorme.Split" Version="26.9.7" />
For projects that support PackageReference, copy this XML node into the project file to reference the package.
<PackageVersion Include="Blazorme.Split" Version="26.9.7" />



                            Directory.Packages.props





<PackageReference Include="Blazorme.Split" />



                            Project file
For projects that support Central Package Management (CPM), copy this XML node into the solution Directory.Packages.props file to version the package.
paket add Blazorme.Split --version 26.9.7






#r "nuget: Blazorme.Split, 26.9.7"
#r directive can be used in F# Interactive and Polyglot Notebooks. Copy this into the interactive tool or source code of the script to reference the package.
#:package Blazorme.Split@26.9.7
#:package directive can be used in C# file-based apps starting in .NET 10 preview 4. Copy this into a .cs file before any lines of code to reference the package.
#addin nuget:?package=Blazorme.Split&version=26.9.7



                            Install as a Cake Addin





#tool nuget:?package=Blazorme.Split&version=26.9.7



                            Install as a Cake Tool

Blazorme.Split

Split component library for Blazor apps. The library provides resizeable split views (panes).

Requires .NET 10. Earlier versions targeted netstandard2.1 and net5.0, which are no longer supported.

Use DemoApp as a reference for your implementation.

Implementation

Currently the library interops by using the split.js package: GitHub, jsdelivr

Installation

  • Install NuGet package:
  Install-Package Blazorme.Split
  • Using:

In _Imports.razor add:

  @using Blazorme
  • JS reference:

Add the following line to your index.html (WebAsembly) or _Host.cshtml (Server) files:


    <script src="https://cdnjs.cloudflare.com/ajax/libs/split.js/1.6.0/split.min.js"></script>

Usage

In your Blazor page, add the top level Split entry and SplitPane sub-entires to form the split view. Here is a simple example:

<div class="container-fluid border border-primary" style="width: 100%; height: 600px">
    <Split>
        <SplitPane SizeInPercentage="20" MinSize="0">
            One
        </SplitPane>
        <SplitPane SizeInPercentage="50" MinSize="0">
            Two
        </SplitPane>
        <SplitPane SizeInPercentage="30" MinSize="0">
            Three
        </SplitPane>
    </Split>
</div>

Parameters

    public enum SplitDirection
    {
        Horizontal,
        Vertical
    }

    public enum SplitGutterAlign
    {
        Center,
        Start,
        End,
    }

Split

Parameter Type Default Description
DefaultMinSize int 100 Minimum size of each pane in pixels. It will be used if min size is not specified in SplitPane.
ExpandToMin bool false Grow initial sizes to min size.
GutterSize int 10 Gutter size in pixels.
GutterAlign SplitGutterAlign SplitGutterAlign.Center Gutter alignment between elements.
GutterColor string "#cfcfcf" Gutter color in HTML hex string.
SnapOffset int 30 Snap to min size offset in pixels.
DragInterval int 1 Number of pixels to drag.
Direction SplitDirection SplitDirection.Horizontal Direction to split, horizontal or vertical.
Cursor string "col-resize" or "row-resize" depending on direction Cursor to display while dragging.

SplitPane

Parameter Type Default Description
SizeInPercentage int 0 Pane size in percentage.
MinSize int? null Minimum size of the pane in pixels.

Example

From demo app:

<div class="container-fluid border border-primary" style="width: 100%; height: 600px">
    <Split GutterSize="5">
        <SplitPane SizeInPercentage="20" MinSize="0">
            Lorem ipsum dolor sit amet, consectetur adipiscing elit. In vel ullamcorper ipsum, at blandit leo. Sed egestas est tellus, nec rutrum leo ultricies vitae. Praesent scelerisque libero in lacus gravida, a ultrices tortor rutrum. Donec et justo nibh. Nulla congue volutpat sapien, eu pretium sapien porttitor id. Vivamus sit amet aliquet libero. Vestibulum sit amet ex pharetra, dapibus enim nec, ullamcorper metus. Integer pellentesque aliquam aliquet.
        </SplitPane>
        <SplitPane SizeInPercentage="50" MinSize="0">
            <Split Direction=@SplitDirection.Vertical GutterSize="5">
                <SplitPane MinSize="0">
                    Lorem ipsum dolor sit amet, consectetur adipiscing elit. In vel ullamcorper ipsum, at blandit leo. Sed egestas est tellus, nec rutrum leo ultricies vitae. Praesent scelerisque libero in lacus gravida, a ultrices tortor rutrum. Donec et justo nibh. Nulla congue volutpat sapien, eu pretium sapien porttitor id. Vivamus sit amet aliquet libero. Vestibulum sit amet ex pharetra, dapibus enim nec, ullamcorper metus. Integer pellentesque aliquam aliquet.
                </SplitPane>
                <SplitPane MinSize="0">
                    Lorem ipsum dolor sit amet, consectetur adipiscing elit. In vel ullamcorper ipsum, at blandit leo. Sed egestas est tellus, nec rutrum leo ultricies vitae. Praesent scelerisque libero in lacus gravida, a ultrices tortor rutrum. Donec et justo nibh. Nulla congue volutpat sapien, eu pretium sapien porttitor id. Vivamus sit amet aliquet libero. Vestibulum sit amet ex pharetra, dapibus enim nec, ullamcorper metus. Integer pellentesque aliquam aliquet.
                </SplitPane>
            </Split>
        </SplitPane>
        <SplitPane SizeInPercentage="30" MinSize="0">
            Lorem ipsum dolor sit amet, consectetur adipiscing elit. In vel ullamcorper ipsum, at blandit leo. Sed egestas est tellus, nec rutrum leo ultricies vitae. Praesent scelerisque libero in lacus gravida, a ultrices tortor rutrum. Donec et justo nibh. Nulla congue volutpat sapien, eu pretium sapien porttitor id. Vivamus sit amet aliquet libero. Vestibulum sit amet ex pharetra, dapibus enim nec, ullamcorper metus. Integer pellentesque aliquam aliquet.
        </SplitPane>
    </Split>
</div>
Product Compatible and additional computed target framework versions.
.NET net10.0 is compatible.  net10.0-android was computed.  net10.0-browser was computed.  net10.0-ios was computed.  net10.0-maccatalyst was computed.  net10.0-macos was computed.  net10.0-tvos was computed.  net10.0-windows was computed.
Compatible target framework(s)
Included target framework(s) (in package)
Learn more about Target Frameworks and .NET Standard.

NuGet packages

This package is not used by any NuGet packages.

GitHub repositories

This package is not used by any popular GitHub repositories.

Version Downloads Last Updated
26.9.14 96 9/14/2026
26.9.9 107 9/8/2026
26.9.7 109 9/7/2026
1.0.1 673 6/12/2021
1.0.0 760 6/17/2020

Modernised for .NET 10. Targets net10.0 only; netstandard2.1 and net5.0 are no longer supported.
Fixed: the component overwrote its own Cursor parameter, so the cursor went stale when Direction changed; the direction and gutter-align options sent to split.js are now lowercased invariantly; SplitPane used outside a Split throws InvalidOperationException instead of a bare Exception.
