Veracity.Core.Api.V4 Documentation

Welcome to the Veracity Platform Graph API SDK for .NET! This comprehensive package enables seamless integration with Veracity's identity and resource management system.

---

Quick Links

• Comprehensive Guide - Full documentation with examples
• Developer Portal - Register your application
• Veracity Platform - Learn about Veracity
• GitHub Repository - Base authentication library

---

What's New in V4

• ? Tenant-centric architecture - All operations organized by tenant
• ?? Fine-grained permissions - Element-level access control
• ?? Element management - Hierarchical resource structures
• ?? Type-safe responses - Strongly-typed extension properties
• ?? Enhanced authorization - Built-in attribute-based protection
• ?? Multi-framework - .NET 6, 7, 8, and 9 support

---

Installation

dotnet add package Veracity.Core.Api.V4

---

Quick Setup

1. Configure appsettings.json

{
  "Veracity": {
    "veracityGraphBaseUrl": "https://api.veracity.com/apiv4/v1",
    "applicationPrefix": "myapp",
  "serviceId": "your-application-id-from-developer",
    "clientId": "your-client-id",
    "clientSecret": "your-client-secret",
    "subscriptionKey": "your-subscription-key",
    "azureAdB2C": {
      "instance": "https://login.microsoftonline.com/tfp/",
      "domain": "dnvglb2cprod.onmicrosoft.com",
      "policy": "B2C_1A_SignInWithADFSIdp",
      "clientId": "your-client-id",
      "callbackPath": "/signin-oidc",
      "scopes": "https://dnvglb2cprod.onmicrosoft.com/83054ebf-1d7b-43f5-82ad-b2bde84d7b75/user_impersonation"
    }
  }
}

2. Configure Services (Startup.cs)

public void ConfigureServices(IServiceCollection services)
{
    // Add Veracity authentication
    services.AddVeracity(Configuration);

    // Add Veracity Graph API
    services.AddVeracityGraphApi<DotNetLogger>();

    // Configure authentication
  services.AddAuthentication(options =>
        {
   options.DefaultScheme = CookieAuthenticationDefaults.AuthenticationScheme;
            options.DefaultChallengeScheme = OpenIdConnectDefaults.AuthenticationScheme;
 })
    .AddVeracityAuthentication(Configuration)
        .AddCookie();

    services.AddControllersWithViews();
}

public void Configure(IApplicationBuilder app, IWebHostEnvironment env)
{
    app.UseHttpsRedirection();
    app.UseStaticFiles();
    app.UseAuthentication();
    app.UseVeracity();
    app.UseAuthorization();

    // Optional: Add profile picture middleware
    app.UseVeracityProfilePicture();

    app.UseRouting();
    app.UseEndpoints(endpoints =>
    {
        endpoints.MapControllerRoute(
      name: "default",
            pattern: "{controller=Home}/{action=Index}/{id?}");
    });
}

3. Use in Your Code

public class MyController : Controller
{
    private readonly IVeracityGraphClient _veracityClient;

    public MyController(IVeracityGraphClient veracityClient)
{
        _veracityClient = veracityClient;
    }

    [VeracityAuthorization]
    [HttpGet("api/tenants/{tenant_id}/users")]
    public async Task<IActionResult> ListUsers(string tenant_id)
    {
   var users = await _veracityClient.Users.FindUsers(
            tenant_id,
   top: 25,
        skip: 0);
     return Ok(users);
    }

    [VeracityAuthorization("admin", "editor")]
    [HttpPost("api/tenants/{tenant_id}/licenses")]
    public async Task<IActionResult> AddLicense(
        string tenant_id,
        [FromBody] Guid userId)
    {
        var license = await _veracityClient.ThisApplication.AddLicense(
   tenant_id,
         new LicenseRequest
    {
 EntityId = userId,
                LicenseType = EntityTypes.profile,
                AccessLevel = "editor"
            });
   return Ok(license);
    }
}

---

Key Features

Tenant Management

// Get tenant information
var tenant = await _veracityClient.Tenants.GetTenant(tenantId);

// List all tenants for your application
var tenants = await _veracityClient.Tenants.GetTenants(applicationId);

// Update tenant properties
var patch = tenant.MakeJsonPatch()
    .AddOrUpdateProperty("customField", "value");
await patch.ExecutePatchTenantAsync();

User Management

// Find user by email
var user = await _veracityClient.Users.GetUserByEmail(tenantId, "user@example.com");

// List users with fluent query builder (recommended)
var users = await _veracityClient.Users.Query(tenantId)
    .Filter(u => u.Name == "John Doe")
    .Or(u => u.Name == "Jane Doe")
    .And(u => u.IsLocked == false)
    .Search("engineer")
    .Top(25)
    .ExecuteAsync();

// Get user's groups and applications
var groups = await _veracityClient.Users.GetGroupsForUser(tenantId, userId);
var apps = await _veracityClient.Users.GetApplicationsForUser(tenantId, userId);

Group Management

// List groups with query builder
var groups = await _veracityClient.Groups.Query(tenantId)
    .Filter(g => g.Name == "Administrators")
    .Or(g => g.Name == "Editors")
    .Top(25)
    .ExecuteAsync();

// Get group members (including nested)
var allMembers = await _veracityClient.Groups.GetMembersWithInheritedMemberships(
    tenantId,
  groupId,
    new Dictionary<string, string>());

// Check if user is member
var isMember = await _veracityClient.Groups.IsUserMemberOfGroup(
    tenantId,
    groupId,
    userId);

Application & License Management

// Get application details
var app = await _veracityClient.ThisApplication.GetApplication(tenantId);

// Verify user has license
var license = await _veracityClient.ThisApplication.VerifyUserLicense(
  tenantId,
    userId);

// Get all users with licenses (including inherited from groups)
var users = await _veracityClient.ThisApplication.GetUsersWithInheritedAccess(
    tenantId);

// Add license to user
var newLicense = await _veracityClient.ThisApplication.AddLicense(
    tenantId,
new LicenseRequest
    {
        EntityId = userId,
        LicenseType = EntityTypes.profile,
AccessLevel = "reader"
    });

Element Management (Application-Specific Resources)

// Create a root element (e.g., workspace, vessel, project)
var element = await _veracityClient.ThisApplicationElements.CreateElement(
    tenantId,
    new ElementRequest
    {
   Name = "My Workspace",
        ElementExternalId = "ws-001",
        ElementType = "Workspace",
        Description = "Main project workspace",
        ElementTypeIconUrl = new Uri("https://cdn.example.com/icon.png")
    });

// Create child element
var child = await element.AddChildElement(new ElementRequest
{
    Name = "Sub-workspace",
    ElementExternalId = "ws-001-sub",
    ElementType = "Workspace"
});

// Grant user access to element
await element.AddRights(new ElementRightRequest
{
    EntityId = userId,
    LicenseType = EntityTypes.profile,
    AccessLevel = "editor"
});

// Get all elements user has access to
var userElements = await _veracityClient.ThisApplicationElements
    .GetUserElements(tenantId, userId);

---

Custom Typed Responses

Create strongly-typed models for your extension properties:

// Define your typed model
public class MyTenant : TypedTenantBase
{
    public List<string> VesselList
    {
        get => GetValue<List<string>>();
    set => SetValue(value);
    }

    public string Department
    {
        get => GetValue<string>();
      set => SetValue(value);
    }

    // Access properties from other applications
    public List<string> ManagementCompanies =>
  GetExternalValue<List<string>>("vtmd2");
}

// Convert response to typed version
var typedTenant = await _veracityClient.Tenants
    .GetTenant(tenantId)
    .ToTyped<MyTenant>();

Console.WriteLine($"Department: {typedTenant.Department}");
Console.WriteLine($"Vessels: {string.Join(", ", typedTenant.VesselList)}");

Supported Base Types:

• TypedTenantBase
• TypedUserBase
• TypedGroupBase
• TypedApplicationBase
• TypedLicenseBase
• TypedMemberBase
• TypedElementBase

---

Authorization Attribute

Protect your endpoints with built-in license verification:

// Basic authorization - verify user has valid license
[VeracityAuthorization]
public async Task<IActionResult> MyAction(string tenant_id)
{
    // User has a valid license
}

// Require specific access levels
[VeracityAuthorization("admin", "editor")]
public async Task<IActionResult> AdminAction(string tenant_id)
{
    // User has admin OR editor access level
}

// Configure tenant ID location
[VeracityAuthorization(
    TenantIdIn = IdCarrierTypes.Path,
    TenantIdKey = "tenant_id",
    CacheWindowSizeInMinutes = 5)]
[HttpGet("api/tenants/{tenant_id}/data")]
public async Task<IActionResult> GetData(string tenant_id)
{
    // Tenant ID extracted from path parameter
}

// Element-level authorization
[VeracityAuthorization(
    ElementIdIn = IdCarrierTypes.Path,
    ElementIdKey = "elementId",
    AccessLevels = new[] { "editor", "owner" })]
[HttpPost("api/elements/{elementId}/data")]
public async Task<IActionResult> UpdateElement(string elementId)
{
 // User has editor or owner rights on the element
}

---

Profile Picture Middleware

Display user profile pictures in your web application:

// Configure in Startup.cs
app.UseVeracityProfilePicture(
    generateInitialsAvatar: true,
  background: Color.DarkBlue,
    text: Color.White);

// Use in Razor views
<img src="@user.ProfilePictureUrl" alt="@user.Name" />

// Or get programmatically
var imageBytes = await user.GetProfileImage();

If a user doesn't have a profile picture, the middleware automatically generates an initials-based avatar.

---

OData Queries

Fluent Query Builder (Recommended)

Use the fluent query builder for type-safe, readable queries:

// Simple filter
var users = await _veracityClient.Users.Query(tenantId)
    .Filter(u => u.Name == "John Doe")
    .Top(25)
    .ExecuteAsync();

// Complex filter with OR and AND combinations
var users = await _veracityClient.Users.Query(tenantId)
    .Filter("tenantId eq 'abc'")              // Initiates filter
    .And(u => u.Name == "John")               // Commits previous, starts new AND group
    .Or(u => u.Name == "Jane")                // Adds OR to current group
    .Or(u => u.Name == "Bob")                 // Adds OR to current group
    .And(u => u.IsLocked == false)            // Commits OR group, adds new AND clause
    .Top(50)
    .OrderBy(u => u.Name)
    .ExecuteAsync();
// Produces: tenantId eq 'abc' and (name eq 'John' or name eq 'Jane' or name eq 'Bob') and isLocked eq false

// Search with filters
var users = await _veracityClient.Users.Query(tenantId)
    .Search("engineer")
    .Filter(u => u.IsLocked == false)
    .Top(25)
    .Skip(0)
    .OrderByDescending(u => u.Name)
    .Select(u => u.Name)
    .Select(u => u.Email)
    .ExecuteAsync();

// Pagination support
if (users.NextPageUrl != null)
{
    var nextPage = await users.GetNextPage();
}

Query Builder Pattern:

• Filter() - Initiates the filter (only use once at the start)
• And() - Commits current group and starts a new AND clause
• Or() - Adds an OR condition to the current group
• Top(), Skip() - Pagination
• OrderBy(), OrderByDescending() - Sorting
• Search() - Free-text search
• Select() - Field projection

Raw OData Queries

For advanced scenarios, you can use raw OData queries:

var query = new OdataRequest
{
    Filter = "name eq 'John Doe' and email ne 'test@example.com'",
    Search = "engineer",
    OrderBy = new[]
    {
        new OrderingElement { Field = "name", Type = OrderTypes.Ascending }
    },
    Top = 25,
    Skip = 0,
    Select = new[] { "name", "email", "userId" }
};

var users = await _veracityClient.Users.ListUsers(tenantId, query);

Supported OData Operators:

• Comparison: eq, ne, gt, lt, ge, le
• Logical: and, or, not
• String: ("search.ismatch('hn', 'name'),("search.ismatch('hn', 'name'), ("search.ismatch('hn', 'name'), ("search.ismatch('hn', 'name')

---

Extension Properties

Manage custom metadata on any entity:

// Add or update properties
var patch = user.MakeJsonPatch()
    .AddOrUpdateProperty("customField", "value")
    .AddOrUpdateProperty("tags", new List<string> { "tag1", "tag2" });
await patch.ExecutePatchUserAsync();

// Remove property
var patch = user.MakeJsonPatch()
 .RemoveProperty("customField");
await patch.ExecutePatchUserAsync();

// Read property
var value = user.GetPropertyValue<string>("customField");

// Read property from another application
var externalValue = user.GetPropertyValue<string>("otherapp", "propertyName");

Properties are automatically prefixed with your application prefix (configured in appsettings.json).

---

Authentication Modes

Authorization Code Flow (Web Applications)

Default mode for interactive user applications:

services.AddAuthentication(options =>
    {
        options.DefaultScheme = CookieAuthenticationDefaults.AuthenticationScheme;
     options.DefaultChallengeScheme = OpenIdConnectDefaults.AuthenticationScheme;
    })
    .AddVeracityAuthentication(Configuration)
    .AddCookie();

Client Credentials Flow (Daemon Applications)

For service-to-service communication:

services.AddVeracityClientCredentialsAuthentication(
    clientId: "your-client-id",
    clientSecret: secureClientSecret);

Note: Update the scope in configuration to:

{
  "Veracity": {
    "azureAdB2C": {
      "scopes": "https://dnvglb2cprod.onmicrosoft.com/83054ebf-1d7b-43f5-82ad-b2bde84d7b75/.default"
    }
  }
}

---

Error Handling

All API operations throw ServerException with detailed error information:

try
{
    var user = await _veracityClient.Users.GetUserByEmail(tenantId, email);
}
catch (ServerException ex)
{
    var error = ex.GetErrorData<ErrorDetail>();

    Console.WriteLine($"Error: {error.Message}");
    Console.WriteLine($"Correlation ID: {error.CorrelationId}");
    Console.WriteLine($"Support Code: {error.SupportCode}");
    Console.WriteLine($"HTTP Status: {ex.Status}");

    // Log for support
    _logger.LogError(ex,
        "API error - Correlation ID: {CorrelationId}",
        error.CorrelationId);
}

Common Status Codes:

• 200 OK - Success
• 400 Bad Request - Invalid parameters
• 401 Unauthorized - Authentication failure
• 403 Forbidden - Insufficient permissions
• 404 Not Found - Resource doesn't exist
• 409 Conflict - Resource conflict
• 500 Internal Server Error - Server error

---

API Interfaces

Main Interfaces

• IVeracityGraphClient - Main entry point
  • Tenants - Tenant operations
  • Users - User operations
  • Groups - Group operations
  • Applications - Application and license operations
  • Elements - Element operations
  • Me - Current user operations
  • ThisApplication - Quick access to your configured application
  • ThisApplicationElements - Quick access to your application's elements

Key Operations by Interface

ITenantsApi

• GetTenant, GetTenants, PatchTenant
• GetAdmin, GetAdmins
• GetUsersAndGroups

IUsersApi

• GetUserByEmail, GetUser, GetUserInTenant
• ListUsers, ResolveUsers
• GetGroupsForUser, GetApplicationsForUser, GetTenantsForUser
• PatchUser

IGroupsApi

• GetGroups, GetGroup
• GetGroupMembers, GetMembersWithInheritedMemberships
• IsUserMemberOfGroup, GetMemberOf
• GetApplications, PatchGroup, PatchMember

IApplicationsApi

• GetApplications, GetApplication
• GetLicenses, VerifyUserLicense, GetUsersWithInheritedAccess
• AddLicense, SetAccessLevel, UpdateLicense, DeleteLicense
• GetAdministrators, PatchApplication

IElementsApi

• ListElements, ListChildElements, GetElementTree
• GetElement, CreateElement, CreateChildElement
• PatchElement, DeleteElement
• GetElementRights, AddElementRights, UpdateElementRights, DeleteElementRights
• GetUserElements, GetUserElement

IMe

• GetMyInfo, GetMyApplications, GetMyTenantApplications
• GetMyGroups, GetMyTenants, GetMyTenantsWithApplication
• VerifyUserPolicy

---

Migration from V3 API

If you're migrating from the V3 API:

Configuration Changes

V3:

services.AddVeracityServices(myApiV3Url);

V4:

services.AddVeracityGraphApi(veracityGraphBaseUrl);

API Changes

V4 uses a tenant-centric approach. All operations now require a tenant context:

V3:

var services = await _my.Services(new UserAndServiceQuery { userId });

V4:

var apps = await _veracityClient.Users.GetApplicationsForUser(tenantId, userId);

Profile Picture

V3: Manual implementation required

V4: Built-in middleware

app.UseVeracityProfilePicture();

---

Console Application Example

using Microsoft.Extensions.Configuration;
using Microsoft.Extensions.DependencyInjection;
using Veracity.Core.Api.V4;

var configuration = new ConfigurationBuilder()
    .AddJsonFile("appsettings.json")
    .Build();

var clientSecret = new SecureString();
foreach (var c in Environment.GetEnvironmentVariable("CLIENT_SECRET"))
{
    clientSecret.AppendChar(c);
}

var services = new ServiceCollection()
    .AddVeracity(configuration)
    .AddVeracityClientCredentialsAuthentication(
   "your-client-id",
 clientSecret)
    .AddVeracityGraphApi()
    .BuildServiceProvider();

using var scope = services.CreateScope();
var client = scope.ServiceProvider.GetRequiredService<IVeracityGraphClient>();

// Use the client
var users = await client.Users.ListUsers(
    "tenant-id",
 new Dictionary<string, string>());

Console.WriteLine($"Found {users.Items.Length} users");

---

Best Practices

1. Use Distributed Caching - Configure Redis or memory cache for better performance
2. Implement Custom Logging - Extend LogAdapter for your logging infrastructure
3. Handle Pagination - Use GetNextPage() for large result sets
4. Use Batch Operations - Prefer ResolveUsers() over loops
5. Proper Extension Property Naming - Use MakePropertyName() for consistency
6. Error Handling - Always catch ServerException and log correlation IDs
7. Access Level Validation - Check if application supports access levels before setting them
8. Don't Dispose Manually - Let IoC container manage IVeracityGraphClient lifetime

---

Support and Resources

Documentation

• Developer Portal - Application registration and management
• API Reference - Complete API documentation

Getting Help

• Technical Issues: Contact Veracity Support with the Correlation ID from error responses
• Integration Questions: Consult the developer portal
• Feature Requests: Contact your Veracity representative

Sample Code

• Review the WebApplicationNet7 project for ASP.NET Core examples
• Check CCTestApp for console application patterns
• See WebApplicationNet7/Controllers/TestApi.cs for API usage examples

---

Version History

v4.2.0 (Current)

• Client credentials flow support
• Multi-framework targeting (.NET 6, 7, 8, 9)
• Enhanced element hierarchy management
• Improved error handling and logging

v4.1.0

• Custom typed response support
• Enhanced OData query support
• Profile picture middleware
• Improved caching strategies

v4.0.0

• Initial V4 release
• Tenant-centric architecture
• Element management
• Enhanced access control
• Server-sent events

---

License

This SDK is provided by DNV and is subject to the terms and conditions of your Veracity Platform agreement.

---

Ready to get started? Check out the Comprehensive Guide for detailed documentation and examples!
