ProCad
ProCad is a .NET 10 CAD inspection, rendering, editing, scripting, and collaboration workspace for DWG and DXF documents. It combines an Avalonia desktop/browser application with reusable CAD viewer/editor controls, an ACadSharp-backed IO layer, a render-scene pipeline, command-based editing services, and a headless trace harness for performance work.
Highlights
- Open, inspect, compare, edit, and save DWG/DXF documents.
- Render model space, paper space, layouts, viewports, plot styles, linetypes, hatches, raster images, underlays, dynamic blocks, XRefs, SHX text, ACIS SAT/SAB geometry, and common 2D/3D entity families.
- Use a Dock-based Avalonia workspace with document tree, property grid, layers, blocks, viewports, entity type filters, style editors, render options, DXF/DWG semantic views, raw DXF, batch tools, scripting, collaboration, diagnostics, and logs.
- Drive edits through command-line and interactive tools for draw, modify, annotation, clipboard, XRef, constraints, undo/redo, and script workflows.
- Embed reusable controls through NuGet packages
ProCadSharp.Controls,ProCadSharp.Controls.Skia,ProCadSharp.Controls.Avalonia,ProCadSharp.Controls.Uno, andProCadSharp.Controls.Maui. - Run render profiling and trace capture through
ProCad.TraceCli. - Build narrative and generated API documentation with Lunet.
Repository Layout
| Path | Purpose |
|---|---|
ProCad |
Avalonia application shell, views, view models, services, docking layout, commands, diagnostics, and render backend integration. |
ProCad.Desktop |
Classic desktop host. |
ProCad.Browser |
Avalonia WebAssembly/browser host. |
ProCad.Core |
CAD domain contracts, metadata, diffing, batch query/search, IO options, and export models. |
ProCad.IO |
ACadSharp-backed DWG/DXF load/save services. |
ProCad.Rendering |
Document-to-render-scene pipeline, entity handlers, hit testing, caching, diagnostics, and performance budgets. |
ProCad.Editing |
CAD commands, sessions, operations, transactions, undo/redo, selection, clipboard, constraints, snaps, grips, and command runtime. |
ProCad.Collaboration |
Realtime operation sharing, presence, conflict handling, snapshot stores, and ProEdit transport adapters. |
ProCad.Scripting |
Roslyn-backed C# scripting and command script integration. |
ProCad.Controls* |
Platform-neutral, Skia, Avalonia, Uno, and MAUI reusable viewer/editor controls. |
ProCad.TraceCli |
Headless rendering and dotnet-trace harness. |
ProCad.*.Tests |
xUnit, rendering, editing, controls, collaboration, service, ViewModel, and Avalonia headless coverage. |
site |
Lunet documentation site and API docs configuration. |
.github/workflows |
Build, docs, and release automation. |
Requirements
- .NET SDK 10.0.x
- Git submodules initialized recursively
- Optional workloads for full local coverage:
wasm-tools,android,ios,maccatalyst,maui-android
git submodule update --init --recursive
dotnet workload restore
dotnet restore ProCad.slnx
Build And Test
dotnet restore ProCad.slnx
dotnet build ProCad.slnx -c Release --no-restore
dotnet test ProCad.slnx -c Release --no-build
Focused test runs are useful during development:
dotnet test ProCad.Tests/ProCad.Tests.csproj -c Release
dotnet test ProCad.Editing.Tests/ProCad.Editing.Tests.csproj -c Release
dotnet test ProCad.Controls.Tests/ProCad.Controls.Tests.csproj -c Release
Run the desktop host:
dotnet run --project ProCad.Desktop/ProCad.Desktop.csproj -c Debug
Run the browser host:
dotnet run --project ProCad.Browser/ProCad.Browser.csproj -c Debug
Packages
The reusable library and control packages are published with ProCadSharp.* package IDs. Project names, assemblies, and namespaces remain ProCad.*.
Create local packages:
dotnet pack ProCad.Core/ProCad.Core.csproj -c Release -o artifacts/packages
dotnet pack ProCad.IO/ProCad.IO.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Rendering/ProCad.Rendering.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Editing/ProCad.Editing.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Scripting/ProCad.Scripting.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Collaboration/ProCad.Collaboration.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Collaboration.ServerHost/ProCad.Collaboration.ServerHost.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Controls/ProCad.Controls.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Controls.Skia/ProCad.Controls.Skia.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Controls.Avalonia/ProCad.Controls.Avalonia.csproj -c Release -o artifacts/packages
dotnet pack ProCad.Controls.Uno/ProCad.Controls.Uno.csproj -c Release -o artifacts/packages
MAUI packages require platform workloads and are packed by the release workflow on macOS.
Trace CLI
ProCad.TraceCli renders one or more files headlessly and can be used with dotnet-trace:
dotnet run --project ProCad.TraceCli -- --input /path/to/file.dxf --visual-style hiddenline
See ProCad.TraceCli/README.md for trace collection and options.
Documentation
The public documentation site is generated with Lunet from site/.
./build-docs.sh
./serve-docs.sh
./check-docs.sh
Generated output is written to site/.lunet/build/www and is published by the Docs workflow to GitHub Pages.
Release
Tags named v* trigger the release workflow. The workflow validates the solution, packs the reusable controls, publishes NuGet packages when NUGET_API_KEY is configured, and creates a GitHub release with generated notes and package artifacts.
License
This repository is licensed under the MIT license.
