OfficeIMO.ChartForgeX is the optional bridge for placing any ChartForgeX VisualArtifact in Word, Excel, PowerPoint, PDF, or another OfficeDrawing consumer, and for projecting supported diagram semantics into native editable Visio. Existing OfficeIMO packages do not acquire a ChartForgeX dependency.

The bridge uses ChartForgeX 2.0. Add ChartForgeX.Visuals when producing factual tables, canvases, or watermark decoration. Add ChartForgeX.Stories only in applications that produce stories or animation. Both optional producers can supply a common static artifact to the bridge; the bridge itself keeps a core-only ChartForgeX dependency.

For source builds, reference OfficeIMO.ChartForgeX.csproj from the consuming project and make the ChartForgeX source projects available through the repository's project-reference configuration. The bridge remains optional: applications that do not reference it keep the standard OfficeIMO dependency graph.

Put a chart in Word

Prepare the chart at its intended document size, then insert its artifact. OfficeVisualDocumentStyle uses point-based typography and the shared light/dark palette. Word constrains an oversized visual to the paragraph's available content width when no explicit size is supplied.

using ChartForgeX.Core;
using ChartForgeX.Primitives;
using ChartForgeX.Rendering;
using ChartForgeX.VisualArtifacts;
using OfficeIMO.ChartForgeX;
using OfficeIMO.Word;

var chart = Chart.Create().AddLine("Revenue", new[] {
    new ChartPoint(1, 42), new ChartPoint(2, 58), new ChartPoint(3, 73)
});
var context = OfficeVisualDocumentStyle.Default.CreateContext(
    frame: new VisualFrame("Quarterly sales", showLegend: false));
var artifact = chart.Prepare(context).ToArtifact("sales-quarter");
artifact.Accessibility.WithTextAlternative("Quarterly sales", "Revenue: 42, 58 and 73.");

using var document = WordDocument.Create("sales.docx");
document.AddParagraph().AddVisualArtifact(artifact);
document.Save();

Produce a portable PDF chart drawing

Use OfficeVisualSvgPolicy.RequireVector when producing a chart for the JavaScript PDF drawing block. Add the same licensed static TrueType faces to OfficeVisualConversionOptions.Fonts before conversion so SVG text measurement uses the faces registered during chart preparation. Call conversion.Report.RequireNoLoss(), then pass conversion.Drawing to OfficeDrawingPortableExporter.TryExportJson in OfficeIMO.Core with the selected font family. The JavaScript consumer loads those same faces separately.

This route uses the existing .NET SVG importer and canonical drawing model. The portable export rejects unsupported paint, fonts and text layout instead of dropping labels or substituting a raster image. See the portable drawing profile for its limits.

Choose the destination

Use the same artifact in each format. Worksheet ranges and slide layout boxes preserve proportions and center the visual within the authored bounds.

paragraph.AddVisualArtifact(artifact);
sheet.AddVisualArtifact("B4:I18", artifact);
slide.AddVisualArtifact(artifact, presentation.SlideSize.GetContentBoxPoints(36));
content.AddVisualArtifact(artifact, spacingAfter: 12);

Word uses the containing cell or owning section, authored columns, margins and direct paragraph indents. paragraph.GetContentWidthPoints() exposes that estimate for preparation. Unequal flowing columns use their smallest authored width. Shared headers with differing section widths and unsupported text boxes require explicit dimensions. This is authored geometry, not Microsoft Word's measured pagination or automatic table layout.

PDF constrains oversized drawings to their actual flow width, including padded containers and columns, without enlarging smaller visuals. Supply a PdfDrawingStyle to explicitly choose placement behavior; set ConstrainToContentWidth = true to retain automatic fitting with custom styling.

Set WidthPoints or HeightPoints for an explicit size. With both supplied, the default Fit = OfficeImageFit.Contain keeps the whole visual within the box without distortion. Choose Stretch explicitly for exact dimensions. Cropped Cover fitting is not supported by this bridge. Slide boxes and worksheet ranges supply their own final placement bounds.

Reuse a conversion and inspect fidelity

The bridge returns an OfficeVisualConversionResult containing:

• SVG or PNG placement bytes for Word, Excel, and PowerPoint, according to the selected SVG policy;
• an OfficeDrawing scene for PDF and drawing pipelines;
• dimensions normalized to points;
• accessible text, metadata-ready regions, and a typed fidelity report.

OfficeVisualConversionResult visual = artifact.ToOfficeVisual(
    new OfficeVisualConversionOptions { WidthPoints = 420 });

paragraph.AddVisualArtifact(visual);
sheet.AddVisualArtifact(2, 2, visual);
slide.AddVisualArtifact(visual, leftPoints: 36, topPoints: 72);

content.AddVisualArtifact(visual);

// Change placement size without rendering or importing the source again.
slide.AddVisualArtifact(visual.WithSize(300), leftPoints: 36, topPoints: 72);
foreach (var diagnostic in visual.Report.FidelityDiagnostics)
    Console.WriteLine($"{diagnostic.Code}: {diagnostic.Message}");

Insertion overloads with out OfficeVisualConversionResult expose the conversion when inserting an artifact directly. Use that result to inspect diagnostics. Report.RequireNoLoss() rejects reported approximations and omissions.

The default RasterizeWhenNeeded policy preserves appearance with vector output when supported and PNG fallback when SVG import is incomplete. Fallback remains a reported approximation, with loss of vector editability. Choose PreserveVector to keep the imported vector scene and report unsupported features, or RequireVector to reject incomplete vector conversion. Word, Excel, and PowerPoint use the selected placement payload; PDF uses the converted OfficeDrawing scene.

Prepared artifacts retain their resolved viewport and accessible text. The default scale is 0.75 points per pixel; PointsPerPixel changes that scale, while WidthPoints or HeightPoints can set the document size explicitly. Raster DPI metadata does not change the chosen placement size.

Choose a viewport and typography for the intended document size before preparing the visual. Reducing a wide chart to a small picture also reduces every label. OfficeVisualDocumentStyle.Default.CreateContext(widthPoints, heightPoints) supplies readable document typography at that size; its font and point sizes are also available for surrounding headings and captions. A custom style can change that scale, while a supplied VisualTheme retains the shared palette and geometry. The document delivery example demonstrates light/dark charts, repeated placements, saved-file previews and editable topology fidelity across the five document formats.

SVG-producing surfaces

Every CFX surface that emits SVG can use the flat Office placement path, even when it does not expose a typed artifact envelope. Wrap the generated markup in OfficeVisualSource:

OfficeVisualConversionResult visual = new OfficeVisualSource(canvas.ToSvg()) {
    Id = "release-overview",
    Title = "Release overview",
    AlternativeText = "Release readiness summary with six status tiles."
}.ToOfficeVisual();

Apply static watermarks before conversion with the Visuals decorator:

artifact.WithWatermarks(VisualWatermark.FromText("Internal"));
OfficeVisualConversionResult visual = artifact.ToOfficeVisual();

Decoration retains the semantic model. Native Visio reports WatermarkNotProjected because its editable page does not project the static watermark layers; the SVG or PNG picture contains them. The same diagnostic and fidelity policy apply when the artifact is passed as an interchange envelope or UTF-8 JSON.

Native editable Visio

Topology, flow, and sequence artifacts can be projected into native OfficeIMO.Visio diagrams. Nodes, containers, connectors, Shape Data, hyperlinks, sequence messages, activations, notes, and fragments remain editable after saving to VSDX. The conversion result includes the document, generated page, validated CFX interchange envelope, and a fidelity report.

using ChartForgeX.VisualArtifacts;
using OfficeIMO.ChartForgeX;

VisualArtifact artifact = topology.Prepare().ToArtifact("service-topology");
OfficeVisioVisualConversionResult visio = artifact.ToOfficeVisio(
    new OfficeVisioVisualOptions { PageName = "Service topology" });

visio.Document.Save("service-topology.vsdx");

if (visio.Report.HasSemanticLoss) {
    foreach (OfficeVisioVisualDiagnostic diagnostic in visio.Report.Diagnostics) {
        Console.WriteLine($"{diagnostic.Code}: {diagnostic.Message}");
    }
}

AllProjectedObjectsEditable reports whether the native objects can be edited independently. HasSemanticLoss is a separate fidelity decision: it becomes true only for warning diagnostics, when Visio cannot represent a source feature exactly, even though every projected shape remains editable. Disabling Shape Data or native hyperlinks is therefore reported when source semantics would otherwise be omitted. Information diagnostics describe lossless normalizations such as collision-safe Shape Data aliases. ArtifactKind preserves how the visual was authored, while SemanticFamily identifies the reusable topology, flow, or sequence projection. Use stable diagnostic codes and severity for automation and Message for logs or user interfaces.

Pass a typed VisualArtifactInterchangeEnvelope directly when the caller shares the same ChartForgeX assembly identity. The adapter validates that object without serializing it first. Use artifact.ToInterchangeUtf8Json() and jsonBytes.ToOfficeVisio() across process or PowerShell assembly-load-context boundaries. Static SVG remains a separate fallback; the adapter does not infer editable semantics by scraping rendered markup. Unsupported artifact families fail closed for native Visio conversion. Complete topology envelopes preserve node and group bounds by default. Coordinates use PixelsPerInch to convert CFX pixels to Visio inches. Unpositioned topology, flow, and sequence inputs use native layout; UseNaturalPageSize keeps the CFX viewport as their minimum page size.

ChartForgeX owns chart and diagram semantics, deterministic rendering, interchange, watermarks, layout, and raster metadata. OfficeIMO owns document placement, native Visio projection, page layout, document/page watermarks, PDF composition, and Office package behavior.

Preserve placement and enforce fidelity

LayoutMode = Auto preserves complete topology bounds and reflows other inputs. Choose Preserve to require prepared topology coordinates, or Reflow to explicitly request native layout. Prepared topology graphs retain their resolved connector routes and label rectangles. Envelopes without a resolved route retain authored connector bends and named port offsets; native route construction is reported when neither is available. Native titles use clear space above the preserved content; when no header band is available, the title is omitted and TitleNotProjected is reported. Native graph styling maps the source page background, card, surface, border, and foreground colors, with Arial text for portable previews. The page fill is a protected native adornment behind the editable graph objects; it keeps the same page count and gives titles and connector captions the intended light or dark surface. Set NativeTheme to override it, for example with VisioStyleTheme.Technical() for the previous native defaults. Curves, advanced edge styling, icons, source fonts, and complete CFX themes still have limits described by the diagnostics.

Flow and sequence remain native editable diagrams with recomputed layout. Their prepared coordinates remain in the interchange envelope, and LayoutRecomputed reports that the native page uses a different layout. Preserve rejects those families instead of claiming exact placement.

var options = new OfficeVisioVisualOptions {
    LayoutMode = OfficeVisioVisualLayoutMode.Preserve,
    PixelsPerInch = 96
};
options.RejectedDiagnostics.Add(OfficeVisioVisualDiagnosticCode.LayoutRecomputed);
var result = envelope.ToOfficeVisio(options);
result.Document.Save("topology.vsdx");

Set RequireLossless = true to reject every warning, or add selected codes to RejectedDiagnostics. A rejected conversion throws OfficeVisioVisualFidelityException; its Report explains the losses. Conversion does not save a file.

Export a report as one document

Pass an ordered sequence of envelopes to ToOfficeVisioBook. Each input becomes one page; repeated titles receive distinct page names. Each result in Pages exposes that page's fidelity report and shares the returned document.

var book = envelopes.ToOfficeVisioBook(options);
book.Document.Save("topology-report.vsdx");

ChartForgeX report pages can supply these envelopes through report.Pages.Select(page => page.ToInterchangeEnvelope()). Project CrossPageLinks into native page links to make every relationship navigable in Visio:

var envelopes = report.Pages.Select(page => page.ToInterchangeEnvelope());
var links = report.CrossPageLinks.Select(link => new OfficeVisioVisualBookLink(
    link.SourcePage, link.SourceNodeId,
    link.TargetPage, link.TargetNodeId,
    link.EdgeId));

var book = envelopes.ToOfficeVisioBookWithNavigation(links, new OfficeVisioVisualBookOptions {
    MaximumNavigationLinksPerEntity = 12,
    IncludeReturnLinks = true
});
book.Document.Save("topology-report.vsdx");

Duplicate targets are coalesced while their relationship identifiers remain in Shape Data. OmittedNavigationCount and CFX.BookLink.Omitted disclose links removed by the per-entity bound. ChartForgeX retains an original node identifier in chartforgex.sourceId whenever interchange projection has to shorten or disambiguate it, so report links still resolve against the editable Visio shape.
