MudBlazor.Extensions 8.14.0

MudBlazor.Extensions

The MudBlazor.Extensions is a convenient package that extends the capabilities of the MudBlazor component library. This guide will demonstrate the setup process for your project, along with detailed explanations of the components, extensions, and functionalities provided. It's important to note that this package requires a MudBlazor project and the referenced MudBlazor package. For further information and assistance, please visit the official MudBlazor documentation at MudBlazor and MudBlazor/Templates.

Demos

Try Online

Table of Contents

• Installation
• Setting Up MudBlazor.Extensions
• Components
  • MudExObjectEdit
  • MudExStructuredDataEditor
  • MudExFileDisplay
  • MudExFileDisplayZip
  • MudExFileDisplayDialog
  • MudExUploadEdit
• Extensions
  • Making Dialogs Resizable and Draggable
  • Adding a Maximize Button
  • Adding Custom Buttons
  • Animation for Showing Dialog
  • Removing Need of DialogParameters

Installation

The installation process is straightforward. All you need to do is add the MudBlazor.Extensions NuGet package to your Blazor project. You can do this using the following code:

<PackageReference Include="MudBlazor.Extensions" Version="*" />

Setting Up MudBlazor.Extensions

Setting up MudBlazor.Extensions involves three steps:

1. Update the _Imports.razor with the following lines:

@using MudBlazor.Extensions
@using MudBlazor.Extensions.Components
@using MudBlazor.Extensions.Components.ObjectEdit

2. Register MudBlazor.Extensions in your Startup.cs in the ConfigureServices method.

// use this to add MudServices and the MudBlazor.Extensions
builder.Services.AddMudServicesWithExtensions();

// or this to add only the MudBlazor.Extensions but please ensure that this is added after mud servicdes are added. That means after `AddMudServices`
builder.Services.AddMudExtensions();

3. (Optional) Define default dialogOptions.

builder.Services.AddMudServicesWithExtensions(c =>
{
    c.WithDefaultDialogOptions(ex =>
    {
        ex.Position = DialogPosition.BottomRight;
    });
});

if your are running on Blazor Server side, you should also use the MudBlazorExtensionMiddleware you can do this in your startup or program.cs by adding the following line on your WebApplication:

    app.Use(MudExWebApp.MudExMiddleware);

(Optional) if you have problems with automatic loaded styles you can also load the styles manually by adding the following line to your index.html or _Host.cshtml

<link id="mudex-styles" href="_content/MudBlazor.Extensions/mudBlazorExtensions.min.css" rel="stylesheet">

If you have loaded styles manually you should disable the automatic loading of the styles in the AddMudExtensions or AddMudServicesWithExtensions method. You can do this by adding the following line to your Startup.cs in the ConfigureServices method.

builder.Services.AddMudServicesWithExtensions(c => c.WithoutAutomaticCssLoading());

Showcase Videos

<details> <summary>Expand videos</summary>

Showcase

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/39e06d88-a947-43cd-9151-a7cf96bcd849

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/3c77b8bf-6198-4385-b452-f25cc2852e0a

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/ce9bdf86-aaf9-4f04-b861-bd57698bb7f5

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/6b054bdc-a413-437c-8dbb-ded4e242d2a7

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/57f39cec-c3e9-43aa-8bfe-260d9aa05f63

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/c6a0e47d-2ed6-4a4e-b2b8-f4963274c9f8

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/3fc658d7-7fa2-487e-98d2-91860e00374a

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/aa266253-f1ac-450d-bd7b-510d2b99e3c0

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/cf4ff772-953e-4462-90fc-b32249083fb8

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/79bccec3-9e04-4901-a7d2-a08c9cef031c

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/8963eaaa-0f96-4c76-8e3c-c945920b2c23

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/cd5bab33-75cd-442d-a156-f43cc3a1c78c

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/8545a70c-1ce2-4683-8f1e-40a69efe462b

https://github.com/fgilde/MudBlazor.Extensions/assets/11070717/5c736020-94ba-431a-94f7-8e437530978e

</details>

Components

This section introduces you to the various components provided by the MudBlazor.Extensions.

MudExObjectEdit

The MudExObjectEdit is a robust component that allows for object editing and automatically generates the corresponding UI. This component supports automatic validation for DataAnnotation Validations or fluent registered validations for your model.

To use MudExObjectEdit, you can simply use the MudExObjectEditForm and pass your model to it as shown below:

<MudExObjectEditForm OnValidSubmit="@OnSubmit" Value="@MyModel"></MudExObjectEditForm>

You can also utilize the MudExObjectEditDialog to edit your model in a dialog. The easiest way to do this is by using the extension method EditObject on the IDialogService.

dialogService.EditObject(User, "Dialog Title", dialogOptionsEx);

More

MudExStructuredDataEditor

The MudExStructuredDataEditor is a component that allows object editing and automatically generates the corresponding UI based on structured data like json, xml or yaml. This component supports all the same as MudExObjectEditForm.

To use MudExStructuredDataEditor, you can simply bind your data string shown as bellow:

    <MudExStructuredDataEditor @bind-Data="_dataString"></MudExStructuredDataEditor>

You can also utilize the MudExStructuredDataEditor to edit your data in a dialog. The easiest way to do this is by using the extension method EditStructuredDataString on the IDialogService.

dialogService.EditStructuredDataString(_dataType, _dataString, $"Auto Generated Editor for {_dataType}", ((_,_) => Task.FromResult("")));

You can find a running Sample here

MudExFileDisplay

The MudExFileDisplay component is designed to display file contents, such as a preview before uploading or for referenced files. This component can automatically handle URLs or streams and deliver the best possible display. Additionally, you can implement IMudExFileDisplay in your own component to register a custom file display. This is excacly what MudExFileDisplayZip does, which is used by MudExFileDisplay to display zip files or what MudExFileDisplayMarkdown does to display markdown files.

Example of using MudExFileDisplay:

 <MudExFileDisplay FileName="NameOfYourFile.pdf" ContentType="application/pdf" Url="@Url"></MudExFileDisplay>

MudExFileDisplayZip

This component can be automatically utilized by MudExFileDisplay, but can also be used manually if necessary. Note: If you're using the ContentStream it should not be closed or disposed.

 <MudExFileDisplayZip AllowDownload="@AllowDownload" RootFolderName="@FileName" ContentStream="@ContentStream" Url="@Url"></MudExFileDisplayZip>

MudExFileDisplayDialog

A small dialog for the MudExFileDisplay Component. It can be used with static helpers as shown below:

 await MudExFileDisplayDialog.Show(_dialogService, dataUrl, request.FileName, request.ContentType, ex => ex.JsRuntime = _jsRuntime);

It can be used directly with an IBrowserFile:

 IBrowserFile file = File;
 await MudExFileDisplayDialog.Show(_dialogService, file, ex => ex.JsRuntime = _jsRuntime);

Or it can be used manually with the MudBlazor dialogService:

var parameters = new DialogParameters
{
    {nameof(Icon), BrowserFileExtensions.IconForFile(contentType)},
    {nameof(Url), url},
    {nameof(ContentType), contentType}
};
await dialogService.ShowEx<MudExFileDisplayDialog>(title, parameters, optionsEx);

More

MudExUploadEdit

MudExUploadEdit is a versatile file upload component with a wide range of features such as MIME and extension whitelisting/blacklisting, folder upload, drag and drop, copy and paste, renaming, and integration with Dropbox, Google Drive, and OneDrive.

More

Extensions

Resizable or Draggable Dialogs

You can make your dialogs resizable or draggable using the following code snippet:

var options = new DialogOptionsEx { Resizeable = true, DragMode = MudDialogDragMode.Simple, CloseButton = true, FullWidth = true };
var dialog = await _dialogService.ShowEx<YourMudDialog>("Your Dialog Title", parameters, options);

Adding a Maximize Button

You can add a maximize button to your dialogs with the following code:

var options = new DialogOptionsEx { MaximizeButton = true, CloseButton = true };
var dialog = await _dialogService.ShowEx<YourMudDialog>("Your Dialog Title", parameters, options);

Adding Custom Buttons

To add custom buttons to your dialog, first define the callback methods as JSInvokable in your component code:

[JSInvokable]
public void AlarmClick()
{
   // OnAlarmButton Click
}

[JSInvokable]
public void ColorLensClick()
{
   // OnColorLensButton Click
}

Next, define your custom buttons:

var buttons = new[]
{
    new MudDialogButton( DotNetObjectReference.Create(this as object), nameof(AlarmClick)) {Icon = Icons.Material.Filled.Alarm},
    new MudDialogButton( DotNetObjectReference.Create(this as object), nameof(ColorLensClick)) {Icon = Icons.Material.Filled.ColorLens},
};

Finally, add your custom buttons to the dialog:

var options = new DialogOptionsEx { MaximizeButton = true, CloseButton = true, Buttons = buttons };
var dialog = await _dialogService.ShowEx<YourMudDialog>("Your Dialog Title", parameters, options);

Your dialog can now look like this:

Using Animation to Show Dialog

You can use animation to display your dialog. This is done by setting the Animation property of DialogOptionsEx.

var options = new DialogOptionsEx {
    MaximizeButton = true,
    CloseButton = true,
    Buttons = buttons,
    Position = DialogPosition.CenterRight,
    Animation = AnimationType.SlideIn,
    AnimationDuration = TimeSpan.FromMilliseconds(500),
    FullHeight = true
};
var dialog = await _dialogService.ShowEx<YourMudDialog>("Your Dialog Title", parameters, options);

When you animate a dialog with dialogServiceEx, it's recommended to add the class mud-ex-dialog-initial to your dialog to ensure no visibility before animation.

<MudDialog Class="mud-ex-dialog-initial">

NOTE: All animations can be used on other components as well. Currently, the following animations are supported: SlideIn,FadeIn,Scale,Slide,Fade,Zoom,Roll,JackInTheBox,Hinge,Rotate,Bounce,Back,Jello,Wobble,Tada,Swing,HeadShake,Shake,RubberBand,Pulse,Flip,FlipX,FlipY.

Using Extension Method with an Action<YourDialog>

Instead of using DialogParameters, you can call the extension method with an Action<YourDialog>

await dialogService.ShowEx<SampleDialog>("Simple Dialog", dialog => { dialog.ContentMessage = "Hello"; },options);

More

Conclusion

This README file provides an overview of the MudBlazor.Extensions library, which is designed to simplify and enhance the development process in Blazor using MudBlazor. The library contains a variety of components, extensions, and features that aim to reduce the time and effort required to build intricate UIs. For additional information or help, visit the official MudBlazor website or MudBlazor GitHub repository.

We hope you find this library helpful and encourage you to provide any feedback or contribute to its development.

License

MudBlazor.Extensions is released under the MIT License. See the bundled LICENSE file for details.

Change Log

Latest Changes:

• 8.14.0 > Update to MudBlazor 8.14.0
• 8.14.0 > Add support for .net 10
• 8.14.0 > Add simple demo for MudExPicker combined with MudExTreeView here
• 8.13.0 > Move MudExComponentPropertyGrid to MudEx, to have the easy possibility to add and component grid
• 8.13.0 > Drag and Drop in MudExGrid here
• 8.13.0 > New GroupMode DockPanel for MudExObjectEdit sample here
• 8.13.0 > New Component MudExDockLayout sample here
• 8.13.0 > New Component MudExGravatarCard sample here
• 8.11.0 > MudExObject edit now supports grouping by tabs and accordions. See sample here
• 8.11.0 > Small bug fixes
• 8.9.0 > Support touch events for dialog dragging
• 8.9.0 > Fixes bug with icon picker if no value is specified
• 8.9.0 > Fixes bug with custom size in non modal dialogs
• 8.9.0 > Update MudBlazor to 8.9.0 and other Packages to latest version
• 8.8.0 > Update MudBlazor to 8.8.0 and other Packages to latest version
• 8.8.0 > Fix Bug in MudExOneDriveFilePicker where the file couldnt be loaded when AutoLoadDataBytes is true
• 8.7.0 > Update MudBlazor to 8.7.0
• 8.7.0 > Fix bug in SnapDrag Mode for dialog

Full change log can be found here

If you like this package, please star it on GitHub and share it with your friends If not, you can give a star anyway and let me know what I can improve to make it better for you.
