LeXtudio.DevFlow.Agent.WinForms

WinForms-specific DevFlow runtime package for instrumenting classic WinForms applications.

This package builds on LeXtudio.DevFlow.Agent.Core and adds the WinForms visual tree walker, screenshot capture, and UI interaction support required for WinForms application automation.

Install

dotnet add package LeXtudio.DevFlow.Agent.WinForms

What is included

  • WinForms visual tree inspection
  • live screenshot capture from the application window
  • element and selector screenshot capture
  • mouse/tap action support for WinForms elements
  • text input, clear, focus, key, and scroll actions for supported controls
  • integration with the shared DevFlow HTTP API

Usage

Register the WinForms DevFlow agent in your application startup:

using System.Windows.Forms;
using LeXtudio.DevFlow.Agent.WinForms;
using Microsoft.Maui.DevFlow.Agent.Core;

internal static class Program
{
    [STAThread]
    private static void Main()
    {
        ApplicationConfiguration.Initialize();

        var form = new MainForm();
        var context = new ApplicationContext(form);
        context.AddWinFormsDevFlowAgent(new AgentOptions { Port = 9223 });

        Application.Run(context);
    }
}

Getting Started

For a complete sample, see WinFormsDevFlowTestApp in this repository.

For common agent endpoints and port configuration notes, see the top-level DevFlow README.

Compatibility

  • .NET 8.0+ on Windows
  • WinForms applications only
