Dosaic.Plugins.Jobs.Hangfire 1.2.40

Dosaic.Plugins.Jobs.Hangfire

Dosaic.Plugins.Jobs.Hangfire is a plugin that allows Dosaic-based services to schedule and manage background jobs using Hangfire. It supports recurring (cron) jobs, fire-and-forget jobs, delayed jobs, PostgreSQL or in-memory storage, a built-in dashboard, OpenTelemetry tracing, Prometheus metrics, and feature-flag-based job execution control.

Installation

dotnet add package Dosaic.Plugins.Jobs.Hangfire

or add as a package reference to your .csproj:

<PackageReference Include="Dosaic.Plugins.Jobs.Hangfire" Version="" />

Configuration

Configure appsettings.yml (or appsettings.json) with the hangfire section:

hangfire:
  # PostgreSQL storage (ignored when inMemory: true)
  host: localhost
  port: 5432
  database: postgres
  user: postgres
  password: postgres

  # Use in-memory storage instead of PostgreSQL (useful for development)
  inMemory: true

  # Hostname from which the Hangfire dashboard is accessible.
  # Leave empty to disable dashboard access entirely.
  allowedDashboardHost: localhost

  # Enable Microsoft Feature Management integration to toggle jobs via config
  enableJobsByFeatureManagementConfig: false

  # Additional queues to listen on (the "default" queue is always included)
  queues:
    - default
    - critical

  # Optional tuning
  pollingIntervalInMs: 5000       # scheduled-job poller interval, defaults to Hangfire built-in value
  workerCount: 10                 # defaults to Hangfire built-in value
  invisibilityTimeoutInMinutes: 30
  maxJobArgumentsSizeToRenderInBytes: 4096  # max bytes of job args displayed in dashboard
  schemaName: hangfire            # PostgreSQL schema holding the Hangfire tables
  queuePollIntervalInMs: 1000     # how often an idle worker asks the queue for work
  useSlidingInvisibilityTimeout: false
  batchChunkSize: 0               # 0 = write a whole batch in exactly one round trip

  # Per queue tuning - every entry gets its own background job server
  queueConfigurations:
    - name: bulk
      workerCount: 100            # workers dedicated to this queue
      prefetchCount: 50           # jobs fetched per polling round trip
      queuePollIntervalInMs: 200
    - name: critical
      workerCount: 10

Configuration class reference

[Configuration("hangfire")]
public class HangfireConfiguration
{
    public string Host { get; set; }
    public int Port { get; set; }
    public string Database { get; set; }
    public string User { get; set; }
    public string Password { get; set; }
    public bool InMemory { get; set; }
    public string AllowedDashboardHost { get; set; }
    public bool EnableJobsByFeatureManagementConfig { get; set; }
    public int? PollingIntervalInMs { get; set; }
    public int? WorkerCount { get; set; }
    public string[] Queues { get; set; } = [EnqueuedState.DefaultQueue];
    public int InvisibilityTimeoutInMinutes { get; set; } = 30;
    public int MaxJobArgumentsSizeToRenderInBytes { get; set; } = 4096;
    public string SchemaName { get; set; } = "hangfire";
    public int QueuePollIntervalInMs { get; set; } = 1000;
    public bool UseSlidingInvisibilityTimeout { get; set; }
    public int BatchChunkSize { get; set; }
    public QueueConfiguration[] QueueConfigurations { get; set; } = [];
    public string ConnectionString => $"Host={Host};Port={Port};Database={Database};Username={User};Password={Password};";
}

public class QueueConfiguration
{
    public string Name { get; set; }
    public int? WorkerCount { get; set; }
    public int PrefetchCount { get; set; } = 1;
    public int? QueuePollIntervalInMs { get; set; }
}

Usage

Defining jobs

Simple async job (no parameters)

Extend AsyncJob and implement ExecuteJobAsync:

public class SendDailyReportJob : AsyncJob
{
    private readonly IReportService _reportService;

    public SendDailyReportJob(ILogger<SendDailyReportJob> logger, IReportService reportService)
        : base(logger)
    {
        _reportService = reportService;
    }

    protected override async Task<object> ExecuteJobAsync(CancellationToken cancellationToken)
    {
        await _reportService.SendAsync(cancellationToken);
        return "done";
    }
}

Parameterized async job

Extend ParameterizedAsyncJob<T> when the job requires input:

public class ProcessOrderJob : ParameterizedAsyncJob<int>
{
    private readonly IOrderService _orderService;

    public ProcessOrderJob(ILogger<ProcessOrderJob> logger, IOrderService orderService)
        : base(logger)
    {
        _orderService = orderService;
    }

    protected override async Task<object> ExecuteJobAsync(int orderId, CancellationToken cancellationToken)
    {
        var result = await _orderService.ProcessAsync(orderId, cancellationToken);
        Logger.LogInformation("Processed order {OrderId}", orderId);
        return result;
    }
}

Note: Job input parameters and results are serialized to JSON and displayed in the Hangfire dashboard. Avoid passing sensitive data as job parameters.

Registering recurring jobs

Option 1 — attribute-based auto-registration

Annotate the job class with [RecurringJob]. The plugin discovers and registers it automatically at startup — no boilerplate required:

[RecurringJob("0 0 * * *")]              // every day at midnight UTC
public class SendDailyReportJob : AsyncJob { ... }

[RecurringJob("0 * * * *", "critical")]  // every hour, on the "critical" queue
public class CriticalHourlyJob : AsyncJob { ... }

The [RecurringJob] attribute accepts a standard cron expression and an optional queue name.

Option 2 — programmatic registration via ConfigureJobs

Register jobs in your plugin or host configuration using the IJobManager API:

public class MyPlugin : IPluginServiceConfiguration
{
    public void ConfigureServices(IServiceCollection serviceCollection)
    {
        serviceCollection.ConfigureJobs((jobs, _) =>
        {
            // simple recurring job
            jobs.RegisterRecurring<SendDailyReportJob>("0 0 * * *");

            // parameterized recurring job (passes the value at registration time)
            jobs.RegisterRecurring<ProcessOrderJob, int>(42, Cron.Daily());

            // recurring job on a specific queue with a name suffix (useful for multiple instances)
            jobs.RegisterRecurring<CriticalHourlyJob>("0 * * * *", queue: "critical", jobSuffix: "v2");
        });
    }
}

Fire-and-forget and delayed jobs via IJobManager

Inject IJobManager to enqueue or schedule jobs programmatically at runtime:

public class OrderController
{
    private readonly IJobManager _jobs;

    public OrderController(IJobManager jobs) => _jobs = jobs;

    public void PlaceOrder(int orderId)
    {
        // fire-and-forget
        _jobs.Enqueue<ProcessOrderJob, int>(orderId);

        // fire-and-forget on a specific queue
        _jobs.Enqueue<ProcessOrderJob, int>(orderId, queue: "critical");

        // simple job (no parameters)
        _jobs.Enqueue<SendDailyReportJob>();

        // delayed execution
        _jobs.Schedule<SendDailyReportJob>(TimeSpan.FromHours(1));
        _jobs.Schedule<ProcessOrderJob, int>(orderId, TimeSpan.FromMinutes(5));
    }
}

Batch creating jobs (IJobManager.CreateBatch)

Creating jobs one by one costs one database round trip per job, which becomes the bottleneck long before the workers do. The batch API collects any number of jobs — including continuation chains between them — and writes all of them with a single SQL statement, so a batch of 100 000 jobs is exactly one round trip.

// simplest form: one job per parameter set
var ids = await jobManager.EnqueueBatchAsync<ProcessOrderJob, int>(orderIds, queue: "bulk");
var sameButSync = jobManager.EnqueueBatch<ProcessOrderJob, int>(orderIds, "bulk");

// or scheduled, relative or absolute
await jobManager.ScheduleBatchAsync<ProcessOrderJob, int>(orderIds, TimeSpan.FromMinutes(5), "bulk");
await jobManager.ScheduleBatchAtAsync<ProcessOrderJob, int>(orderIds, tomorrowAtThree, "bulk");
jobManager.ScheduleBatch<ProcessOrderJob, int>(orderIds, TimeSpan.FromMinutes(5), "bulk");

For anything more involved, build the batch explicitly. Continuations are declared on the batch item handle and are resolved inside the same statement, so the antecedent job id never has to travel back to the application first:

var batch = jobManager.CreateBatch();

foreach (var orderId in orderIds)
{
    var import = batch.Enqueue<ImportOrderJob, int>(orderId, "bulk");
    var enrich = import.ContinueWith<EnrichOrderJob, int>(orderId, "bulk");
    enrich.ContinueWith<NotifyOrderJob, int>(orderId, options: JobContinuationOptions.OnAnyFinishedState);
}

batch.Schedule<CleanupJob>(TimeSpan.FromHours(1), "maintenance");

var jobIds = await batch.SaveAsync();   // one round trip
var firstImportId = jobIds[0];

IJobBatch supports Enqueue, Schedule, ScheduleAt and, on every returned IJobBatchItem, ContinueWith. After SaveAsync() each item exposes its Id.

Enqueueing, scheduling and chaining can be mixed freely in one batch, and all of it still costs one round trip:

var batch = jobManager.CreateBatch();

batch.Enqueue<ImportOrderJob, int>(orderId, "bulk");                       // runs now
batch.ScheduleAt<CleanupJob>(tomorrowAtThree, "maintenance");              // runs at a fixed time

var nightly = batch.Schedule<ReportJob, int>(tenantId, TimeSpan.FromHours(8), "reports");
nightly.ContinueWith<MailReportJob, int>(tenantId, "reports");             // chained off a scheduled job

var root = batch.Enqueue<ImportOrderJob, int>(orderId, "bulk");
root.ContinueWith<EnrichOrderJob, int>(orderId, "bulk");                   // fan-out: two continuations
root.ContinueWith<AuditOrderJob, int>(orderId, "audit",
    JobContinuationOptions.OnAnyFinishedState);                            // on the same antecedent

await batch.SaveAsync();

A continuation runs as soon as its antecedent finishes; there is no "continue with a delay". Hangfire cannot route a delayed continuation to a queue (the queue is not carried on the awaiting job), so if you need a delayed follow-up, schedule it as its own batch entry or put [Queue] on the job type.

Things worth knowing:

• Chaining is batch local. ContinueWith links two jobs of the same batch. Continuing on a job that already exists in the storage still goes through BackgroundJob.ContinueJobWith, because it has to merge into the antecedent's continuation list under a distributed lock.
• Client side filters are bypassed. The bulk write goes straight to the storage, so state election filters do not run for batched jobs — they issue their own queries and would defeat the single round trip. Server side filters (EnabledByFeatureFilter, LogJobExecutionFilter, [JobTimeout], retries) are unaffected.
• [UniquePerQueue] is the exception. Its fingerprint claim is folded into the same statement, so batched jobs are deduplicated without an extra round trip. A job that loses its claim is never written and gets a null id back (IJobBatchItem.IsSuppressed); continuations of a suppressed job are suppressed with it.
• Non-PostgreSQL storages still work. With inMemory: true, or when an IHangfireConfigurator brings its own storage, the batch falls back to creating the jobs through the regular Hangfire client — same API, without the single round trip guarantee.
• batchChunkSize caps how many jobs go into one statement. It defaults to 0 (no cap). Chunking never splits a continuation chain.
• Pickup latency. The bulk write does not raise Hangfire's in-process "queue changed" signal, so idle workers pick batched jobs up on their next poll — queuePollIntervalInMs (1000 ms by default, instead of Hangfire's 15 seconds).

Verifying it against a real database

The batching and prefetching behaviour is covered by Testcontainers integration tests that start a real PostgreSQL, let Hangfire create its real schema, and assert against it — including that a 1000 job batch produces exactly one statement in PostgreSQL's own query log, that batched jobs are indistinguishable from jobs created by BackgroundJobClient, and that a batched continuation chain actually executes in order on a running BackgroundJobServer.

They are marked [Explicit] + [Category("Integration")], so a normal dotnet test skips them and never needs Docker:

dotnet test Plugins/Jobs/Hangfire/test/Dosaic.Plugins.Jobs.Hangfire.Tests --filter TestCategory=Integration

Tuning queues for high volume (workers and prefetching)

Each entry in queueConfigurations gets its own background job server, which makes worker count and fetch behaviour tunable per queue instead of globally:

hangfire:
  workerCount: 20                 # used by the shared server and as fallback
  queues: [default, critical]
  queueConfigurations:
    - name: bulk
      workerCount: 100
      prefetchCount: 50
      queuePollIntervalInMs: 200

• workerCount — workers dedicated to that queue. Queues without an entry stay on the shared server and use the global workerCount.
• prefetchCount — jobs pulled out of the queue per round trip. Hangfire's stock PostgreSQL queue runs one UPDATE ... LIMIT 1 per job; with prefetchCount: 50 a single query hands 50 jobs to the workers. This is the main throughput lever when a queue is used as a message bus replacement. Values greater than 1 require the built-in PostgreSQL storage.
• queuePollIntervalInMs — how long an empty queue waits before asking again. The global default of 1000 ms replaces Hangfire's 15 second default, which is far too slow for bus-like workloads.

Prefetched jobs are marked as fetched immediately, so they are invisible to other servers for invisibilityTimeoutInMinutes. A worker only asks for a job when it is free, so at most prefetchCount - 1 jobs are ever buffered; size the prefetch to what your workers can drain quickly and enable useSlidingInvisibilityTimeout when jobs run longer than the invisibility window.

Querying job state via IJobManager

IJobManager exposes monitoring APIs to inspect the current state of the job store:

// all recurring jobs
IList<RecurringJobDto> recurring = jobManager.GetRecurringJobs();

// recurring jobs for a specific type, with optional predicate
IList<RecurringJobDto> myJobs = jobManager.GetRecurringJobs<ProcessOrderJob>();

// enqueued, processing, failed, fetched — all support type-filtered overloads
IList<EnqueuedJobDto>   enqueued   = jobManager.GetEnqueuedJobs<ProcessOrderJob>();
IList<ProcessingJobDto> processing = jobManager.GetProcessingJobs();
IList<FailedJobDto>     failed     = jobManager.GetFailedJobs();

// unified view across all states with optional predicate
IList<JobEntity> all = jobManager.GetJobs(e => e.Type == JobType.Failed);

// delete a recurring or background job
jobManager.DeleteRecurring("ProcessOrder");
jobManager.Delete(backgroundJobId);

Dashboard

The Hangfire dashboard is mounted at /hangfire. Access is restricted to the host configured in allowedDashboardHost. If the value is empty or not set, access is denied for all hosts.

Attributes

[RecurringJob(cronPattern, queue)]

Marks a class for automatic recurring job registration at startup. Accepts a cron pattern and an optional queue name.

[RecurringJob("*/5 * * * *", "default")]
public class PollExternalApiJob : AsyncJob { ... }

[JobTimeout(timeout, TimeUnit)]

Cancels the job after the specified duration. The cancellation token passed to ExecuteJobAsync is cancelled automatically.

[JobTimeout(30, TimeUnit.Seconds)]
public class QuickJob : AsyncJob { ... }

Supported TimeUnit values: Milliseconds, Seconds, Minutes, Hours, Days.

[JobTimeZone(TimeZoneInfo)]

Specifies the time zone used for cron schedule evaluation of recurring jobs (default: UTC).

[JobTimeZone(/* TimeZoneInfo.FindSystemTimeZoneById("Europe/Berlin") */)]
public class LocalTimeCronJob : AsyncJob { ... }

[UniquePerQueueAttribute(queue)]

Prevents duplicate job executions. If a job with the same type and arguments is already queued, the new one is deleted instead of enqueued. The attribute also owns the queue of the jobs it guards — whatever queue you pass at enqueue time is overridden by the one on the attribute.

[UniquePerQueueAttribute("default")]
public class ImportDataJob : AsyncJob { ... }

Optional properties:

• CheckScheduledJobs — also block while an equivalent job is only scheduled (default: false)
• CheckRunningJobs — also block while an equivalent job is being processed (default: false)
• ClaimTimeoutInMinutes — how long a claim survives without being released, as a safety net for processes that died mid-flight (default: 1440). PostgreSQL only.

How the check works

The job's identity — type, method, arguments and queue — is hashed into a fingerprint, and that fingerprint is claimed in a Hangfire set (dosaic:unique:<queue>) that has a unique index on (key, value). Enqueueing writes the claim; the storage decides who wins. The claim is released again when the job leaves the checked states (when it starts processing, or when it succeeds, fails or is deleted if CheckRunningJobs is set).

That makes the check cost one round trip regardless of queue depth — the previous implementation paged through every enqueued, scheduled and processing job on every single enqueue, so a batch of N jobs against a queue of depth M cost O(N·M). It also closes the race the scan had: two clients enqueueing the same job at the same time could both find nothing and both enqueue.

On PostgreSQL the claim is a single INSERT ... ON CONFLICT, and it rides along inside the batch statement, so [UniquePerQueue] now applies to jobs created through the batch API too. On other storages (in-memory, storages brought by an IHangfireConfigurator) the check falls back to a distributed lock around the set — correct, but unable to take over a claim whose owner died.

Differences to the previous queue-scanning implementation

The attribute's own surface is unchanged — same constructor, same Queue, CheckScheduledJobs and CheckRunningJobs, same DeletedState reason — but a few edge cases behave differently:

• The batch API now honours it. Previously batched jobs were never deduplicated. Duplicates are now suppressed and come back with a null id, and the attribute's queue wins over the queue passed to Enqueue/Schedule, exactly as it always did outside the batch.
• CheckScheduledJobs blocks at scheduling time, not when the scheduled job is enqueued. Under the old scan, scheduling the same job five times let all five through, and the first one to reach the queue then deleted itself because its four siblings were still in the schedule set.
• A job whose worker died no longer blocks. With CheckRunningJobs = false the claim is released when the job starts processing. If the worker then dies and the job is requeued by the invisibility timeout, an equivalent job is allowed in; the old scan would have blocked it.
• On non-PostgreSQL storages a claim outlives its owner. The fallback cannot detect an expired claim, so a process that dies between claiming and releasing blocks that fingerprint until the set entry is removed. On PostgreSQL ClaimTimeoutInMinutes covers this.
• During a rolling upgrade jobs enqueued by the old code hold no claim, so one duplicate per fingerprint can slip through until the queue has drained once.

[JobCleanupExpirationTimeAttribute(days)]

Controls how many days job results are retained in the storage backend before deletion.

[JobCleanupExpirationTimeAttribute(14)]
public class ArchiveJob : AsyncJob { ... }

Filters

LogJobExecutionFilter (always active)

Automatically logs a structured message at the start and finish of every job execution using the job's own logger type.

EnabledByFeatureFilter (opt-in)

Gates job execution on a feature flag using the Microsoft Feature Management system. Enable via configuration:

hangfire:
  enableJobsByFeatureManagementConfig: true

featureManagement:
  SendDailyReportJob: true   # job class name is the feature flag name
  ProcessOrderJob: false     # this job will be skipped

Works with both file-based feature management and the Dosaic Unleash plugin for dynamic runtime feature flags. Since the flag is resolved before each job execution, changes take effect at runtime with a delay based on how frequently the feature management source is refreshed.

Custom storage / server configuration (IHangfireConfigurator)

Implement IHangfireConfigurator (a IPluginConfigurator) to plug in a custom Hangfire storage backend or to configure the background server options:

public class MyHangfireConfigurator : IHangfireConfigurator
{
    // Set to true if your Configure() call registers a storage backend,
    // so the plugin skips its default PostgreSQL storage setup.
    public bool IncludesStorage => true;

    public void Configure(IGlobalConfiguration config)
    {
        config.UseRedisStorage("localhost:6379");
    }

    public void ConfigureServer(BackgroundJobServerOptions options)
    {
        options.WorkerCount = 5;
    }
}

ConfigureServer is invoked once per background job server, so with queueConfigurations it runs for the shared server and for every dedicated queue server. It runs last, which means a configurator that sets WorkerCount or Queues overrides the per-queue configuration — use options.Queues to tell the servers apart if you only want to touch one of them.

When a configurator supplies the storage (IncludesStorage => true, or by calling UseStorage in Configure), the batch API falls back to creating jobs through the regular Hangfire client: the bulk statement talks to the connection string from hangfire: configuration and must never be pointed at someone else's storage.

All IHangfireConfigurator implementations are discovered automatically by the Dosaic plugin system.

Observability

Health check

A Hangfire readiness health check is registered automatically and is accessible via the standard Dosaic health endpoints (/health/readiness). It verifies that at least one Hangfire server is running.

OpenTelemetry tracing

Hangfire jobs are automatically instrumented with OpenTelemetry tracing via OpenTelemetry.Instrumentation.Hangfire.

In addition, every AsyncJob / ParameterizedAsyncJob<T> body runs inside a wrapper span emitted on the shared Dosaic ActivitySource (Tracing.SourceName):

• Span name — GetType().FullName of the concrete job
• Status — set to Ok on success, Error (with the exception attached) on failure
• Log scope — job.type is also pushed onto the ILogger scope for the duration of the job

To enrich the span with business identifiers (e.g. tenant id, message id), override EnrichActivity:

public class ProcessOrderJob : ParameterizedAsyncJob<OrderId>
{
    protected override void EnrichActivity(Activity activity, OrderId value)
    {
        activity?.SetTag("order.id", value.ToString());
    }

    protected override Task<object> ExecuteJobAsync(OrderId value, CancellationToken ct) { ... }
}

AsyncJob has the same hook with the single-argument EnrichActivity(Activity activity) signature. Default implementation is a no-op.

PostgreSQL polling-noise filter

Hangfire's PostgreSQL job-storage polls the hangfire.* schema continuously, which produces a high volume of low-value SQL spans on whatever database instrumentation is enabled (Npgsql, EF Core, etc.). HangFirePlugin registers HangfireSqlNoiseProcessor as the first OpenTelemetry processor in the pipeline; it inspects db.statement / db.query.text / db.statement.text plus the activity display/operation name and clears ActivityTraceFlags.Recorded on any span referencing the hangfire schema, so the OTLP batch exporter drops them before send. No configuration knob — the filter is on whenever the Hangfire plugin is active.

Prometheus metrics

A background service (HangfireStatisticsMetricsReporter) collects Hangfire statistics every 60 seconds and publishes them as OpenTelemetry gauges:

Job naming convention

The job ID used by Hangfire is derived from the class name by stripping the Job and Async suffixes. For example:

• SendDailyReportJob → SendDailyReport
• ProcessOrderAsyncJob → ProcessOrder

When registering the same job type multiple times with jobSuffix, the suffix is appended: ProcessOrder_v2.

Further reading

• Official Hangfire documentation
• Hangfire best practices
